Cable Ties for temperatures up to + 105°C (heat stabilised) T30LL

T-Series in PA66HS black, Article number: 111-03640

Features

  • Available in a wide range of materials and sizes
  • High tensile strength with very low insertion force
  • Only high quality plastic is used meeting recycling targets
  • Inside serrated cable ties for a strong hold onto bundles
  • Ergonomic bent tail offers quick and simple installation
  • Easy application either manually or with an application tool

Certifications & Approvals

Application

These cable ties are used for routing, bundling and securing of cables, pipes and hoses.

T-Series in PA66HS black is suitable for following markets and industries

Application Tool MK3PNSP2, MK3SP, MK20, EVO7
Colour Black (BK)
Description Short (BMEcat) (max. 150 characters) Cable Tie 290x3.5 black
Fixation Method None
GLOBAL PART NAME T30LL-PA66HS-BK
Identification Plate Position none
Pack Cont. 1000
Package Quantity per pieces
Product Family T-Series in PA66HS black
Product Group Cable Ties for temperatures up to + 105°C (heat stabilised)
Releasable Closure (Yes/No) No
Tie Closure plastic pawl
Type T30LL.HB7E
Variant Inside Serrated
Bundle ∅ max. 80.0mm
Bundle ∅ min. 1.5mm
Length (L) 290mm
Min.Tensile Strength 135N
Thickness (T) 1.2mm
Width (W) 3.5mm
Flammability UL 94 V2
Halogenfree Yes
Material Polyamide 6.6, heat stabilised (PA66HS)
Operating Temperature - °C -40 °C to +105 °C, (+145 °C, 500 h)
Specifications
Specifications UL-ZODZ2.E85319
EAN / GTIN 4031026206646
Packaging 1 - Height (m) 0.037m
Packaging 1 - Length (m) 0.330m
Packaging 1 - Qty 1000
Packaging 1 - Type Bag
Packaging 1 - Volume (m³) 0.00501
Packaging 1 - Weight (kg) 1.4700kg
Packaging 1 - Width (m) 0.410m
Packaging 3 - Height (m) 0.37m
Packaging 3 - Length (m) 0.41m
Packaging 3 - Qty 8000
Packaging 3 - Type Carton
Packaging 3 - Volume (m³) 0.0485
Packaging 3 - Weight (kg) 12.46kg
Packaging 3 - Width (m) 0.32m
Packaging 4 - Height (m) 1.11m
Packaging 4 - Length (m) 1.15m
Packaging 4 - Qty 144000
Packaging 4 - Type pallet
Packaging 4 - Volume (m³) 0.932
Packaging 4 - Weight (kg) 244.0kg
Packaging 4 - Width (m) 0.73m
Packaging Content SKU Unit pieces
Weight 1.39kg
ETIM 5.0 EC000046
ETIM 6.0 EC000046
