1-Piece Fixing Ties with Arrowhead, with Disc T80SSF6.5F

1-Piece Fixing Ties with Arrowhead, with Disc, for round holes, Article number: 150-39392

Features

  • Easy to install without the need for a tool
  • Arrowhead simply locks into place
  • Disc adjusts tie for pressures from various directions and minimises access of dust, dirt and water
  • Cable tie head always situated in a defined position
  • KSFT-types with specially rounded arrowhead minimise the assembly height

Certifications & Approvals

Application

With a diverse range of fixing possibilities these ties are ideal for use in many different industries, including automotive, aerospace, white goods manufacture and panel building.

1-Piece Fixing Ties with Arrowhead, with Disc, for round holes is suitable for following markets and industries

Application Tool MK3PNSP2, MK3SP, MK7P, MK20, EVO7, EVO7SP
Colour Grey (GY)
Fixation Method Arrowhead
GLOBAL PART NAME T80SSF6.5F-PA46-GY
Identification Plate Position none
Pack Cont. 1000
Package Quantity per Bag
Product Family 1-Piece Fixing Ties with Arrowhead, with Disc, for round holes
Product Group 1-Piece Fixing Ties with Arrowhead, with Disc
Releasable Closure (Yes/No) No
Tie Closure plastic pawl
Type T80SSF6.5F.RE7P
Variant Inside Serrated
Bundle ∅ max. 43.0mm
for Hole ∅ (FH) 6.3 - 6.5 mm
for Panel Thickness min - max 0.6 - 3 mm
Length (L) 179mm
Min.Tensile Strength 225N
Width (W) 4.6mm
Flammability UL 94 V2
Material Polyamide 4.6 (PA46)
Operating Temperature - °C -40 °C to +150 °C
Specifications
EAN / GTIN 4031026217437
Packaging 1 - Qty 1000
Packaging 1 - Type Bag
Packaging 1 - Weight (kg) 1.6000kg
Packaging Content SKU Unit pieces
Weight 1.6kg
ETIM 5.0 EC000046
ETIM 6.0 EC000046
