Cable label, self laminating, white/transparent, thermal transfer print, 25.40x50.80mm, H2=187.20mm, 250pcs.
Art.-No. 596-70896
| TAG07TD1-896-CL/WH
|
Details
- High-quality self-laminating labels
- Suitable for marking of wires and cables
- Laminating function gives excellent protection against humidity and mechanical abrasion
- Rounded edge design gives additional bonding strength
- Other colours available on request
Request your individual offer now
Request quote
More products in this product group:
| Application | The specially formulated adhesive labels give the highest quality print clarity when printed on thermal transfer printers. The range of materials and ribbons have been developed to suit the needs of most users. Designing and printing labels is simple and users can quickly print out professional labels in a matter of moments when using TagPrint Pro labelling software. |
| Application Method | The functionality and durability of the labels can be negatively affected if improperly processed or applied. All surfaces to be bonded must be clean, dry as well as free from dust and grease. Avoid touching the adhesive surface of the label as this could impair the application performance. |
| Chem. Material Properties | flame retardant, resistant to oils, water and wide range of solvents. |
| Colour | White (WH), Transparent (CL) |
| Material | Type 896, Vinyl (896) |
| Mech. Material Properties | permanent adhesive |
| PART DESCRIPTION | TAG07TD1-896-CL/WH |
| Pack Cont. | 250pcs. |
| Package Content packed in | Reel |
| Product Family | Helatag 896 |
| Product Group | Self-laminating labels "Ladder Style", thermal transfer |
| Self adhesive (Yes/No) | Yes |
| Type | TAG07TD1 |
| Variant | Roller form |
|
|
| Bundle Diameter max (metric) | 47.50mm |
| Bundle ∅ | 20.80-47.50mm |
| Bundle ∅ min. | 20.80mm |
| Height (H) | 25.40mm |
| Height (H2) | 187.20mm |
| Print Method | thermal transfer print |
| Thickness (T) | 75µm |
| Thickness of Foil | 80 |
| Thickness of foil test method | ASTM D3652-83 |
| VR | 196.80mm |
| Weight/Unit | 0.002168kg |
| Width (W) | 50.80mm |
| Width of Liner (WL) | 55.00mm |
Download
| Adhesive | Acrylic |
| Curing Temperature | from +10 °C |
| ELV compliant Dir. Art. 4 (2) | YES |
| Halogen-free | No |
| Hazardous Goods | No |
| Initial tack | 110g/cm² |
| Initial tack | ASTM D2979-71 |
| Operating Temperature | -40 °C to +80 °C |
| Peel strength | 550 N/m |
| Peel strength test method | PSTC 7 |
| Pre-Printed | No |
| ROHS compliant | Yes |
| Recommended Ribbon Type | TT932DOUT |
| Shear strength | 120h |
| Shear strength test method | FINAT FTM 8 |
| Shelf Life | Minimum 1 year upon receipt / maximal 2 years after production date. |
| Specifications |
|
| UL Recognized (US and Canada) | Yes |
| Country of Origin | DE |
| Customs Number | 39199080 |
| GTIN-13 / EAN | 4031026709079 |
| Labels per Row | 1pc. |
| Packaging 1 - Height (m) | 0.055m |
| Packaging 1 - Length (m) | 0.21m |
| Packaging 1 - Qty | 250 |
| Packaging 1 - Type | Bag |
| Packaging 1 - Volume (m³) | 0.00231m³ |
| Packaging 1 - Weight (kg) | 0.542kg |
| Packaging 1 - Width (m) | 0.2m |
| Storage Temperature | +21 °C |
| Storage conditions | 50% relative humidity., The storage in the original packaging is recommended., Please avoid warehousing under impacts such as high humidity, heat and coldness. |
