WH | Details

High-quality self-laminating labels
Suitable for marking of wires and cables
Laminating function gives excellent protection against humidity and mechanical abrasion
Rounded edge design gives additional bonding strength
Other colours available on request

Request your individual offer now

Request quote

Distributors near you

More products in this product group:

Application	The specially formulated adhesive labels give the highest quality print clarity when printed on thermal transfer printers. The range of materials and ribbons have been developed to suit the needs of most users. Designing and printing labels is simple and users can quickly print out professional labels in a matter of moments when using TagPrint Pro labelling software.
Application Method	The functionality and durability of the labels can be negatively affected if improperly processed or applied. All surfaces to be bonded must be clean, dry as well as free from dust and grease. Avoid touching the adhesive surface of the label as this could impair the application performance.
Chem. Material Properties	flame retardant, resistant to oils, water and wide range of solvents.
Colour	White (WH), Transparent (CL)
Colour Marking Field	White (WH)
Material	Type 896, Vinyl (896)
Mech. Material Properties	permanent adhesive
PART DESCRIPTION	TAG107TD3-896-CL/WH
Pack Cont.	1000pcs.
Package Content packed in	pcs.
Product Family	Helatag 896
Product Group	Self-laminating labels "Ladder Style", thermal transfer
Self adhesive (Yes/No)	Yes
Short Description	Self-laminating labels, thermal transfer 25,40x31,75x149,86 mm white-transparent
Type	TAG107TD3
Variant	Roller form


Bundle Diameter max (metric)	37.50mm
Bundle ∅	12.00-37.50mm
Bundle ∅ min.	12.00mm
HR	25.40mm
Height (H)	31.75mm
Height (H2)	149.86mm
Print Method	thermal transfer print
Thickness (T)	75µm
Thickness of Foil	80
Thickness of foil test method	ASTM D3652-83
VR	152.40mm
Weight/Unit	0.000771kg
Width (W)	25.40mm
Width of Liner (WL)	82.00mm

Adhesive	Acrylic
Curing Temperature	from +10 °C
ELV compliant Dir. Art. 4 (2)	YES
Halogen-free	No
Hazardous Goods	No
Initial tack	110g/cm²
Initial tack	ASTM D2979-71
Operating Temperature	-40 °C to +80 °C
Peel strength	550 N/m
Peel strength test method	PSTC 7
Pre-Printed	No
ROHS compliant	Yes
Recommended Ribbon Type	TT932DOUT
Shear strength	120h
Shear strength test method	FINAT FTM 8
Shelf Life	Minimum 1 year upon receipt / maximal 2 years after production date.
Specifications
UL Recognized (US and Canada)	Yes


Country of Origin	DE
Customs Number	39199080
GTIN-13 / EAN	4031026209968
Labels per Row	3pcs.
Packaging 1 - Height (m)	0.15m
Packaging 1 - Length (m)	0.165m
Packaging 1 - Qty	1000
Packaging 1 - Type	Bag
Packaging 1 - Volume (m³)	0.00223m³
Packaging 1 - Weight (kg)	0.771001kg
Packaging 1 - Width (m)	0.09m
Packaging 3 - Height (m)	0.24m
Packaging 3 - Length (m)	0.55m
Packaging 3 - Qty	12000
Packaging 3 - Type	Carton
Packaging 3 - Volume (m³)	0.0515m³
Packaging 3 - Weight (kg)	9.752kg
Packaging 3 - Width (m)	0.39m
Storage Temperature	+21 °C
Storage conditions	50% relative humidity., The storage in the original packaging is recommended., Please avoid warehousing under impacts such as high humidity, heat and coldness.
