Cable Ties Polyamide 6.6 standard T250X

T-Series in PA66 black, Article number: 111-25102

Features

  • Available in a wide range of materials and sizes
  • High tensile strength with very low insertion force
  • Only high quality plastic is used meeting recycling targets
  • Inside serrated cable ties for a strong hold onto bundles
  • Ergonomic bent tail offers quick and simple installation
  • Easy application either manually or with an application tool

Certifications & Approvals

Application

These cable ties are used for routing, bundling and securing of cables, pipes and hoses.

T-Series in PA66 black is suitable for following markets and industries

Application Tool MK9P, EVO9HT
Colour Black (BK)
Description Short (BMEcat) (max. 150 characters) Cable Tie 370x12.5 black
Fixation Method None
GLOBAL PART NAME T250X-PA66-BK
Identification Plate Position none
Pack Cont. 100pcs.
Package Quantity per Bag
Product Family T-Series in PA66 black
Product Group Cable Ties Polyamide 6.6 standard
Releasable Closure (Yes/No) No
Tie Closure plastic pawl
Type T250X.NB3P
Variant Inside Serrated
Bundle ∅ max. 100mm
Bundle ∅ min. 25.0mm
Length (L) 370mm
Min.Tensile Strength 1115N
Width (W) 12.5mm
ELV compliant Dir. Art. 4 (2) YES
Flammability UL 94 V2
Halogenfree Yes
Hazardous goods No
Material Polyamide 6.6 (PA66)
Operating Temperature - °C -40 °C to +85 °C, (+105 °C, 500 h)
Specifications
Specifications BV 03856/H0 BV
EAN / GTIN 5022660021855
Packaging 1 - Height (m) 0.043m
Packaging 1 - Length (m) 0.602m
Packaging 1 - Qty 100
Packaging 1 - Type Bag
Packaging 1 - Volume (m³) 0.00365
Packaging 1 - Weight (kg) 0.625kg
Packaging 1 - Width (m) 0.141m
Packaging 3 - Height (m) 0.371m
Packaging 3 - Length (m) 0.414m
Packaging 3 - Qty 1500
Packaging 3 - Type Carton
Packaging 3 - Volume (m³) 0.0488
Packaging 3 - Weight (kg) 9.995kg
Packaging 3 - Width (m) 0.318m
Packaging 4 - Height (m) 1.258m
Packaging 4 - Length (m) 1.2m
Packaging 4 - Qty 27000
Packaging 4 - Type pallet
Packaging 4 - Volume (m³) 1.208
Packaging 4 - Weight (kg) 200.91kg
Packaging 4 - Width (m) 0.8m
Packaging Content SKU Unit pieces
ETIM 5.0 EC000046
ETIM 6.0 EC000046
