Three-Pronged Pliers for Sleeves and Grommets : NA1K/3

Three-Pronged Plier NA1/3, Article number: 621-10103

Features

  • To easy affix expandable sleeves of every type onto cables/connectors
  • Sleeve simply slide onto the prongs
  • Push pliers and pull over cable
  • Close pliers, sleeve is placed easily
  • Hellerine lubricant recommended for easy operation

Certifications & Approvals

Application

Three-pronged expansion tools are used to ensure speedy and precise application of expandable markers and sleeves.

Colour Metal (ML)
Description Expansion tool NA1/3
Package Quantity per pcs.
PART DESCRIPTION NA1K/3-ML
Product Family NA Tool Range
Product Group Three-Pronged Pliers for Sleeves and Grommets
Replaceable pin Yes
Short Description Three-Pronged Plier NA1/3
Type NA1K/3
Bundle ∅ max. 5.00mm
Bundle ∅ min. 2.50mm
Length (L3) 28.0
Max. length of marker 28mm
∅ D max. 11.0mm
CAS Number 7439-92-1
Critical Substance Lead concentration bushing > 0.1 < 0.35 %
EC Number 231-100-4
ELV compliant Dir. Art. 4 (2) YES
Hazardous good No
Nato number 5120-12-329-4565
Specifications
EAN / GTIN 4031026185194
Packaging 1 - Height (m) 0.075m
Packaging 1 - Length (m) 0.145m
Packaging 1 - Qty 1
Packaging 1 - Type Bag
Packaging 1 - Volume (m³) 0.00082
Packaging 1 - Weight (kg) 0.28kg
Packaging 1 - Width (m) 0.075m
Packaging 3 - Height (m) 0.35m
Packaging 3 - Length (m) 0.57m
Packaging 3 - Qty 50
Packaging 3 - Type Carton
Packaging 3 - Volume (m³) 0.0738
Packaging 3 - Weight (kg) 14.5kg
Packaging 3 - Width (m) 0.37m
Packaging 4 - Height (m) 1.195m
Packaging 4 - Length (m) 1.2m
Packaging 4 - Qty 600
Packaging 4 - Type pallet
Packaging 4 - Volume (m³) 1.147
Packaging 4 - Weight (kg) 195.0kg
Packaging 4 - Width (m) 0.8m
Weight 0.28kg
ETIM 6.0 EC000385
ETIM 7.0 Key EC002808
