Cable tie outside serrated for narrow space, 185x9mm, ⌀4-42mm, black, 100pcs.
Art.-No. 112-00082
| SPH175-PA66HIRUV(REC)-BK
|
Copied
- Made from a blend of post-industrial and post-consumer recycled PA66
- Excellent UV resistance for long-term outdoor use (20 years)
- Outside serration design with an anti-slip feature on the inside to prevent lateral movement of sensitive cables and bundles
- Low profile head, ideal for use in narrow spaces
- Low insertion force enables quick, tool-free manual installation
- Pre-locking position supports secure placement before final installation
- Installer-friendly packaging: belt clip and multiple openings
Show more
Show less
Request quote
More products in this product group:
| Application | The low profile head cable ties from the SPH-Series meet a wide range of needs. They can be installed both indoors and outdoors, thanks to their UV resistance. They are particularly valued for cable tray installations as well as in the construction sector. These ties are also increasingly used in industrial applications. |
| Colour | Black (BK) |
| Fixation Method | Cable Tie |
| Identification Plate Position | none |
| Key product features | for narrow space |
| Material | Polyamide 6.6 recycled, high impact modified, UV-stabilised (PA66HIRUV(REC)) |
| Mechanical Strength | 500N |
| Min.Tensile Strength | 500N |
| PART DESCRIPTION | SPH175-PA66HIRUV(REC)-BK |
| Package Content | 100pcs. |
| Product Family | SPH-Series |
| Product Group | Cable ties with low profile head |
| Releasable Closure (Yes/No) | No |
| Short Description | Cable tie with low profile head 185x9 mm in PA66HIRUV(REC) black - SPH175 |
| Tie Closure | plastic pawl |
| Type | SPH175 |
| UV-Stabilised | Yes |
| Variant | Outside Serrated |
| Weight/Unit | 0.0031kg |
| Flammability | UL 94 HB |
| Halogen-free | Yes |
| Hazardous Goods | No |
| Operating Temperature | -40 °C to +85 °C, (+105 °C, 500 h) |
| PEP File Link (FR) | Link |
| ROHS compliant | Yes |
| Specifications |
|
|
|
Source products are manufactured with plastics recovered from recycled waste or marine environments, derived from renewable plant-based sources, or use materials with lower equivalent emissions. HellermannTyton also offers product solutions that – by design – reduce waste or support reusability and recyclability. ReSource highlights HellermannTyton products that are made from recycled waste or from virgin materials with relatively lower carbon emissions. |
| Country of Origin | FR |
| Customs Number | 3926909790 |
| GTIN-13 / EAN | 4031026770499 |
| Packaging 1 - Height (m) | 0.088m |
| Packaging 1 - Length (m) | 0.209m |
| Packaging 1 - Qty | 100 |
| Packaging 1 - Type | Box |
| Packaging 1 - Volume (m³) | 0.0018392m³ |
| Packaging 1 - Weight (kg) | 0.3151kg |
| Packaging 1 - Width (m) | 0.100m |
| Packaging 3 - Height (m) | 0.250m |
| Packaging 3 - Length (m) | 0.600m |
| Packaging 3 - Qty | 2000 |
| Packaging 3 - Type | Carton |
| Packaging 3 - Volume (m³) | 0.06m³ |
| Packaging 3 - Weight (kg) | 6.99kg |
| Packaging 3 - Width (m) | 0.400m |
| Packaging 4 - Height (m) | 1.3m |
| Packaging 4 - Length (m) | 1.2m |
| Packaging 4 - Qty | 32000 |
| Packaging 4 - Type | pallet |
| Packaging 4 - Volume (m³) | 1.248m³ |
| Packaging 4 - Weight (kg) | 136.84kg |
| Packaging 4 - Width (m) | 0.8m |
