1-Piece Fixing Ties for Weld Studs, for Heavy Duty Applications WSS250

WS-Series for 6.35 mm threaded studs, Article number: 157-00400

Features

  • Very flexible strap provides minimum pinching of soft hoses and convoluted tubing
  • Low profile head for compact bundling
  • Clamping rails to increase grip on round bundles
  • Flexible hinge

Certifications & Approvals

Application

Wide strap stud-mounted cable ties are primarily designed for use in the automotive or truck industry.

WS-Series for 6.35 mm threaded studs is suitable for following markets and industries

Colour Black (BK)
Fixation Method Weld Stud Fixing
Identification Plate Position none
Pack Cont. 300Bag
Package Quantity per Bag
PART DESCRIPTION WSS250-PA66HIRHSUV-BK
Product Family WS-Series for 6.35 mm threaded studs
Product Group 1-Piece Fixing Ties for Weld Studs, for Heavy Duty Applications
Releasable Closure (Yes/No) No
Tie Closure plastic pawl
Type WSS25-HIRHS-BK-D1
Variant Inside Serrated
Bundle ∅ max. 57.1mm
Bundle ∅ min. 9.5mm
Length (L) 246.4mm
Min.Tensile Strength 534N
Stud ∅ M6
Stud ∅ (imperial) 1/4"
Width (W) 12.7mm
ELV compliant Dir. Art. 4 (2) YES
Flammability UL 94 HB
Hazardous good No
Material Polyamide 6.6, high impact modified, heat and UV-stabilised (PA66HIRHSUV)
Operating Temperature - °C -40 °C to +110 °C
Specifications
UL Listed (US and Canada) No
UL Recognized (US and Canada) No
EAN / GTIN 4031026312613
Packaging 1 - Qty 300
Packaging 1 - Type Bag
Packaging 1 - Weight (kg) 1.38kg
Packaging 3 - Height (m) 0.215m
Packaging 3 - Length (m) 0.512m
Packaging 3 - Qty 1200
Packaging 3 - Type Carton
Packaging 3 - Volume (m³) 0.0347
Packaging 3 - Weight (kg) 6.13kg
Packaging 3 - Width (m) 0.315m
Packaging 4 - Length (m) 1.2m
Packaging 4 - Qty 24000
Packaging 4 - Type pallet
Packaging 4 - Weight (kg) 143.6kg
Packaging 4 - Width (m) 0.8m
Weight 1.38kg
ETIM 6.0 EC000046
ETIM 7.0 Key EC000046
UNSPSC Key 39121717
