Category 6 SD Unshielded U/UTP Dca Cable
Art.-No. 851-05109
| CA203
|
Copied
- Small Diameter Cable 5.2mm
- Exceeds Category 6 performance standards
- CPR Euroclass rating: Dca
- Suitable for Cca, Dca and Eca specified inatallations
- Metre marked for accurate measuring
- Supplied in sturdy Reelex boxes of 305m
- 25 Year System Performance Warranty
Show more
Show less
Request quote
More products in this product group:
| Colour | Violet (VT) |
| Description | Category 6 SD (Small Diameter) U/UTP Cable from HellermannTyton is supplied in boxes of 305m and Conforms to CPR Euroclass rating B2ca. The cable is marked at 1m intervals for accurate measuring. |
| PART DESCRIPTION | CA203 |
| Package Content | 1 |
| Package Content packed in | Box |
| Performance Category | Category 6, Category 6 (Class E) |
| Product Family | Dca Cable |
| Product Group | Category 6 SD Unshielded U/UTP |
| Short Description | Category 6 SD Unshielded U/UTP Dca Cable |
| Technical Description |
The Category 6 SD Cable is constructed as a U/UTP Cable and exceeds the relevant performance requirements of ISO/IEC 11801-2 and TIA/ANSI 568-C.2 EN50173, IEC 61156-5, EN 50288-10-1. The LSHF-FR sheath conforms with fire rating IEC 60332-1, 60332-3-24, 60754-2 and 61034. The copper conductor is AWG 24 and the cable has an nominal overall diameter of 5.2mm. Suitable for PoE applications Type 1-4, however HellermannTyton recommends using Category 6A for PoE Type 3 and 4. This cable exceeds with the requirements within the Construction Products regulations EN50575:2014+A1:2016 - Power, control and communication cables. Cables for general applications in construction works subject to reaction to fire requirements. |
| Type | CA203 |
| Typical Application |
Primary (Campus), Secondary (Riser), Tertiary (Horizontal) IEEE 802.3: 10Base-T; 100Base-T; 1000Base-T; IEEE 802.5 16 MB; ISDN; TPDDI; ATM Power over Ethernet (PoE) / Type 1-4 |
