Heat shrinkable tubing 4:1 (32/8 mm), adhesive lined, transparent / black, 1.2 m
Art.-No. 301-10025 | SA47-LA-32.0/8.0-PO-X-BK/CL Details

  • Standard wall polyolefin heat shrink tubing
  • Industry leading corrosion protection
  • Excellent tensile strength and strain relief
  • Provides excellent moisture protection
  • Tubing is clear and hot melt adhesive black
  • Provides environmental sealing of complex parts
  • Halogen free
Show more

Request your individual offer now

Application SA47-LA is a semi-rigid halogen free polyolefin tubing with an inner liner of hot melt adhesive. It has excellent tensile strength and strain relief. The adhesive liner provides superb moisture protection. Ideal for electrical connections and splices in automobiles. Tubing is transparent and hot melt adhesive is black. SA47-LA is specially designed with less adhesive for cable connections.
Behaviour at Heat Shock not cracking
Colour Transparent (CL), Black (BK)
Heat Shock Test 4h/225°C
Key product features bimetallic corrosion protection
Material Polyolefin, cross-linked (PO-X)
PART DESCRIPTION SA47-LA-32.0/8.0-PO-X-BK/CL
Pack Cont. 1.2m
Package Content packed in pcs.
Printable No
Product Family SA47-LA - up to +125°C, strong adhesive, electrochemical corrosion protection
Product Group 4:1 heat shrink tubing - 1.2m lengths & customized cut lengths
Short Description Heat shrinkable tubing 4:1 (32/8 mm), adhesive lined, transparent / black, 1.2 m
Shrink Ratio 4:1
Type SA47-LA-32.0/8.0
Variant Thin-Wall
With inner glue (Yes/No) Yes
Length (L) 1.2m
Longitudinal Change After Shrinkage -10% max.
Recov. ∅ d 8.0mm
Supplied ∅ D 32.0mm
Wall (WT) 2.5mm
Weight/Unit 0.087718kg
Adhesive EVA hot melt adhesive
CAS Number 119-47-1
Critical Substance BisphenolC23H32O2, 1-5 %
Dielectric Strength 20kV/mm
EC Number 204-327-1
ELV compliant Dir. Art. 4 (2) YES
Elongation at break 450%
Halogen-free Yes
Hazardous Goods No
Melting Point starting from +110 °C
Minimum Shrink Temperature +130 °C
Operating Temperature -40 °C to +125 °C
ROHS compliant Yes
Specifications
Tensile Strength 14MPa
UL Listed (US and Canada) No
UL Recognized (US) No
Volume Resistance 10¹³ Ω cm
Water Absorption 0.5%
Country of Origin JP
Customs Number 39173200
GTIN-13 / EAN 4031026492162
Packaging 1 - Height (m) 0.032m
Packaging 1 - Length (m) 1.2m
Packaging 1 - Qty 1
Packaging 1 - Type pcs.
Packaging 1 - Volume (m³) 0.00123
Packaging 1 - Weight (kg) 0.088kg
Packaging 1 - Width (m) 0.032m
Packaging 2 - Height (m) 0.09m
Packaging 2 - Length (m) 1.2m
Packaging 2 - Qty 10
Packaging 2 - Type Bag
Packaging 2 - Volume (m³) 0.0162
Packaging 2 - Weight (kg) 0.877181kg
Packaging 2 - Width (m) 0.15m
Packaging 3 - Height (m) 0.27m
Packaging 3 - Length (m) 1.27m
Packaging 3 - Qty 50
Packaging 3 - Type Carton
Packaging 3 - Volume (m³) 0.084
Packaging 3 - Weight (kg) 4.886kg
Packaging 3 - Width (m) 0.245m
Packaging 4 - Height (m) 1.445m
Packaging 4 - Length (m) 1.2m
Packaging 4 - Qty 600
Packaging 4 - Type pallet
Packaging 4 - Volume (m³) 1.387
Packaging 4 - Weight (kg) 79.631kg
Packaging 4 - Width (m) 0.8m
ETIM 7.0 Key EC000217
ETIM 8.0 Key EC000217
ETIM 9.0 Key EC000217
UNSPSC Key 39121723
