Bottle Shapes, VG style
Art.-No. 401-52885
| 152-42-GWM250-PO-X-BK
|
Copied
- Straight plug-and-socket connector terminal casing
- Protects against environmental stresses for circular plug connectors
- Inside lip for reinforced stress relief
- Special 199-4-G fitting for audio plugs has external ribs for improved grip
Request quote
More products in this product group:
| Application | Heat Shrinkable moulded shapes for use in Electrical and Electronic Cable Harness Applications. |
| Colour | Black (BK) |
| Local order number | 152-42-GWM250 |
| Material | Polyolefin, cross-linked (PO-X) |
| PART DESCRIPTION | 152-42-GWM250-PO-X-BK |
| Package Content | 1pc. |
| Package Content packed in | pcs. |
| Product Family | Helashrink 150 Series, with rib |
| Product Group | Bottle Shapes, VG style |
| Shrink Ratio | 4:1 |
| Type | 152-42-GWM250 |
| Variant | For plug |
| Weight/Unit | 0.004kg |
|
|
|
| ⌀H max b | 10.5mm |
| ⌀H min a | 24mm |
| ⌀J max b | 6mm |
| ⌀J min. a | 24mm |
| Flexibility | Semi rigid |
| For Object Outside Diameter | 13.2-21.3 mm |
| HW ± 20% | 1.6mm |
| JW ± 20% | 0.5mm |
| JW ± 30% | 1.0mm |
| P ± 10% | 38mm |
| R nom | 21mm |
| R ± 10% | 21mm |
| S nom | 10mm |
| T ± 20% | 1mm |
| Tube Shape | Bottle |
| V max | 3.3mm |
| V ± 10% | 3mm |
| Wire Size Range (mm²) | 6.0-23.0mm |
| Adhesive | WM250 |
| CAS Number | 84852-53-9 |
| Critical Substance | DBDPE |
| Dielectric Strength | 14kV/mm |
| Dielectric Strength test method | ASTM D2671 |
| EC Number | 284-366-9 |
| ELV compliant Dir. Art. 4 (2) | Yes |
| Flammability | ASTM D635 |
| Hazardous Goods | No |
| Minimum Shrink Temperature | +135 °C |
| Operating Temperature | -70 °C to +150 °C |
| ROHS compliant | Yes |
| Shelf Life | 5 years |
| Specifications |
|
|
|
|
| Country of Origin | GB |
| Customs Number | 39174000 |
| GTIN-13 / EAN | 5022660430794 |
| Minimum Order Quantity | 1 |
| Packaging 1 - Height (m) | 0.02m |
| Packaging 1 - Length (m) | 0.18m |
| Packaging 1 - Qty | 1 |
| Packaging 1 - Type | Bag |
| Packaging 1 - Volume (m³) | 0.000576m³ |
| Packaging 1 - Weight (kg) | 0.004001kg |
| Packaging 1 - Width (m) | 0.16m |
