Bottle Shape with Rib VG-Style for Plugs black, PO-X, up to 4,5:1
Art.-No. 401-54880 | 154-42-G-PO-X-BK Details

  • Use in conjunction with circular grooved adaptors
  • Strengthened strain relief by usage of an additional inner lip
  • Excellent protection against environment impacts
  • Eliminates moisture ingress to harness

Request your individual offer now

Application Heat Shrinkable moulded shapes for use in Electrical and Electronic Cable Harness Applications.
Application Tool H6100, E4500, CHG900
Colour Black (BK)
Local order number VG95343T06B003A
Material Polyolefin, cross-linked (PO-X)
Pack Cont. 1pc.
Package Content packed in pcs.
PART DESCRIPTION 154-42-G-PO-X-BK
Product Family Helashrink 150 Series, with rib
Product Group Bottle Shapes, VG style
Short Description Bottle Shape with Rib VG-Style for Plugs black, PO-X, up to 4,5:1
Shrink Ratio up to 4.5:1
Variant For plug
Flexibility Semi rigid
HW ± 20% 1.8mm
JO ± 10% 13.0mm
JW ± 20% 1.0mm
JW ± 30% 1.0mm
P ± 10% 55.0mm
R nom 32.0mm
R ± 10% 32.0mm
S nom 13.0mm
T ± 20% 1.0mm
V max 3.3mm
V ± 10% 3.0mm
V ± 20% 3.0mm
Weight/Unit 0.0064kg
∅H max b 14.0mm
∅H min a 30.0mm
∅J max b 6.0mm
∅J min. a 30.0mm
Designation as per VG-Norm VG 95343 T06 B 003 A
Dielectric Strength 14kV/mm
Dielectric Strength test method ASTM D2671
ELV compliant Dir. Art. 4 (2) YES
Flammability ASTM D635
Hazardous Goods No
Minimum Shrink Temperature - °C +135 °C
Nato number 5970-12-196-5899, 5970-99-911-5801
Operating Temperature -75 °C to +150 °C
Specifications
Specifications VG 95343-6
Country of Origin GB
Customs Number 39174000
GTIN-13 / EAN 5022660634840
Packaging 1 - Height (m) 0.035m
Packaging 1 - Length (m) 0.13m
Packaging 1 - Qty 1
Packaging 1 - Type Bag
Packaging 1 - Volume (m³) 0.00046
Packaging 1 - Weight (kg) 0.006401kg
Packaging 1 - Width (m) 0.1m
ETIM 7.0 Key EC002464
ETIM 8.0 Key EC002464
ETIM 9.0 Key EC002464
UNSPSC Key 39121721
