Singleway Bottle Sleeve
Art.-No. 417-88001 | 1788-3-B8WM252-PO-X-BK |

Copied

    Add to watchlist

    Request your individual offer now

     Request quote
    Downloads
    Application For sealing a sacrificial anode connection, suitable for direct burial or total water immersion. Suitable for 75mm (3in) and 100mm (4in) Anodes.
    Colour Black (BK)
    Local order number 1788-3-B8WM252
    Material Polyolefin, cross-linked (PO-X)
    PART DESCRIPTION 1788-3-B8WM252-PO-X-BK
    Package Content 1pc.
    Package Content packed in Bag
    Product Family Helashrink 1700 Series
    Product Group Singleway Bottle Sleeve
    Shrink Ratio 2:1
    Type 1788-3-B8WM252
    ⌀H max b 40mm
    ⌀H min a 115mm
    ⌀J max b 6mm
    ⌀J min. a 19mm
    Flexibility Semi rigid
    P ± 10% 165mm
    R ± 10% 90mm
    S ± 10% 50mm
    Adhesive WM252
    Dielectric Strength 15kV/mm
    Flammability ASTM D635
    Minimum Shrink Temperature +135 °C
    Operating Temperature -50 °C to +80 °C
    ROHS compliant Yes
    Shelf Life 5 years
    Specifications
    Tensile Strength 15MPa
    Country of Origin GB
    GTIN-13 / EAN 5022660440250
    ETIM 7.0 Key EC002464
    ETIM 8.0 Key EC002464
    ETIM 9.0 Key EC002464
    UNSPSC Key 39121721
    Heat shrink tubing Heat shrink tubing

    Heat shrink tubing

    You are looking for the heat shrink tubing meeting your application requirements best? The key factors to which we owe our success are the unique and quite specific properties of our heat shrink tubing.
