Label, weather resistant/chemical resistance, silver, thermal transfer print, 19.05x25.40mm
Art.-No. 596-31796 | TAG31TD3-796-SR-796-SR |

Copied

    This product is not available anymore.
    • Adhesive labels made of vinyl, white gloss
    • Specially tailored to the sizes of IT marking ties and IMP tag range
    • Suitable for permanent marking of components and devices on different surfaces
    • Adheres to rounded surfaces
    • Excellent print performance using TT822OUT ribbon
    • Print with TT4000+, XXXNEW for best results
    • Easy label design with TagPrint Pro2 (version 3 coming soon)
    Add to watchlist

    Request your individual offer now

     Request quote
    Application The use of our specially formulated adhesive labels printed on thermal transfer printers give the highest quality print clarity. The range of materials are complemented by ribbons developed to suit the needs of most users.
    The production of labels is very simple. All that is needed is the required label to be selected from our industry leading software TagPrint Pro.
    Colour Silver matt (SR)
    Key product features weather resistant, chemical resistance
    Material Type 796, Polyester, silver matt (796)
    PART DESCRIPTION TAG31TD3-796-SR-796-SR
    Package Content packed in pcs.
    Product Family Thermal Transfer Labels
    Product Group Inventory and Name Plates Labels
    Self adhesive (Yes/No) Yes
    Type TAG31TD3-796-SR
    H printable 19.05mm
    HR 28.57
    Height (H) 19.05mm
    Print Method thermal transfer print
    Thickness (T) 51µm
    VR 22.86
    Width (W) 25.40mm
    Width of Liner (WL) 85.09mm
    Adhesive Acrylic
    Curing Temperature from +5 °C
    Halogen-free Yes
    Operating Temperature -40 °C to +150 °C
    Pre-Printed No
    ROHS compliant Yes
    Specifications
    Specifications UL
    Country of Origin DE
    GTIN-13 / EAN 4031026212272
    Labels per Row 3
    Packaging 1 - Qty 5000
    Packaging 1 - Weight (kg) 0.7300kg
    Packaging 3 - Qty 5000
    Packaging 4 - Length (m) 1.20m
    Packaging 4 - Type pallet
    Packaging 4 - Width (m) 0.80m
    ETIM 7.0 Key EC001288
    ETIM 8.0 Key EC001288
    ETIM 9.0 Key EC001288
