24/06/2026

suitbale cable 4mm²、6mm²


Art.-No. 721-00002

| PVP_HT20_P_SET-PA66GF25/MET-BK

 |

Copied
PVP_HT20_P_SET

    • Wide operating temperature range from -40 °C to 85°C
    • UL94-V0 flame retardant certification
    • IP68 protection
    • UV resistant
    • Certified by TUV/UL/IEC/CE standards
    • NEC locking system provides security and can be unlocked using the hand-operated tool
    Add to watchlist
    Request quote
    Downloads
    Application PVP-HT20 connectors offer quality connections for the photovoltaic industry. It uses high quality materials that guarantee long-term reliability, lower contact resistance and higher current transfer capability to ensure high product efficiency.
    Colour Black (BK)
    Local order number PVP_HT20_PSET-PA66GF25/MET-BK
    Material Polyamide 6.6, glass-fibre reinforced (PA66GF25), Metal (MET)
    PART DESCRIPTION PVP_HT20_P_SET-PA66GF25/MET-BK
    Package Content 100pcs.
    Package Content packed in Bag
    Product Family PVP-HT20_P_SET
    Product Group PV-Connector
    Short Description suitbale cable 4mm²、6mm²
    Type PVP_HT20_P_SET
    Diameter (D) 18.8mm
    Height (H) 64.5mm
    Resistance (+Accuracy) ≤0.5mΩ
    Flammability UL 94 V0
    Halogen-free Yes
    IP-Rating IP68
    Limited Fire Hazard Yes
    Operating Temperature -40 °C to +85 °C
    ROHS compliant Yes
    Specifications
    Country of Origin CN
    GTIN-13 / EAN 4031026751467
