Fitting for corrugated tubing, nom⌀10mm, M12, black, 10pcs.
Art.-No. 166-21000 | HG10-S-M12-PA66-BK

Copied
  • One piece, fast fit
    High pull-off strength
    Highly resistant to solvents and oils
    Free of halogen, sulphur and phosphorus
    Metric threads supplied with locknuts

Request your individual offer now

Application Straight external thread.
Brass Thread (Y/N) No
Colour Black (BK)
Local order number HG10-S-M12-PA66-BK-10ST
Material Polyamide 6.6 (PA66)
PART DESCRIPTION HG10-S-M12-PA66-BK
Package Content 10pcs.
Package Content packed in Bag
Product Family HG-S Straight, IP66
Product Group Fittings with fixed external thread
Short Description Straight fitting with external thread IP66 ø10mm M12
Strain Relief Function (Y/N) No
Swivel Thread (Y/N) No
Thread type metric
Type HG10-S-M12
Type of connection Snap-connection
Variant Straight
Weight/Unit 0.005772kg
Length (L) 33mm
Length (L2) 9mm
Lowest inner diameter 7.5mm
Min. Bore Size (B) 7.5mm
NW ⌀ 7.5mm
Nominal ⌀ 10mm
Nominal ⌀ (imperial) 0.38"
Outside ⌀ max (OD max.) 19mm
Thread Length (TL) 9mm
Thread Size M12
ELV compliant Dir. Art. 4 (2) YES
Flammability UL 94 V2
Halogen-free Yes
Hazardous Goods No
IP-Rating IP66
Operating Temperature -50 °C to +135 °C
ROHS compliant Yes
Specifications
Specifications ANSI/UL 1695
UL OCD link Link
UL Recognized (US and Canada) Yes
UL-File Number E325250
Country of Origin GB
Customs Number 39174000
GTIN-13 / EAN 4031026302829
Packaging 1 - Height (m) 0.02m
Packaging 1 - Length (m) 0.23m
Packaging 1 - Qty 10
Packaging 1 - Type Bag
Packaging 1 - Volume (m³) 0.000736
Packaging 1 - Weight (kg) 0.057721kg
Packaging 1 - Width (m) 0.16m
Packaging 2 - Height (m) 0.216m
Packaging 2 - Length (m) 0.3048m
Packaging 2 - Type Carton
Packaging 2 - Volume (m³) 0.0176
Packaging 2 - Width (m) 0.267m
ETIM 7.0 Key EC001176
ETIM 8.0 Key EC001176
ETIM 9.0 Key EC001176
