Thermal transfer ribbon, W=60.0mm, black, 300m
Art.-No. 556-00111 | TT822OUT 60MM-PET-BK Details

  • Thermal transfer ribbons for highest quality and performance of printed labels
  • Ribbons are specifically designed to maximise print performance for the recommended material

Request your individual offer now

e-Learning
Application The thermal transfer print technology is based on heating up certain dots in the print head. This transfers the ink very precisely from the ribbon onto the surface of the printed material.
Colour Black (BK)
Local order number TT822OUT60MM
Material Polyester Film (PET)
PART DESCRIPTION TT822OUT 60MM-PET-BK
Pack Cont. 1pc.
Package Content packed in pcs.
Product Family Adhesive Labels
Product Group Thermal Printer Ribbons for adhesive labels
Short Description Thermal Transfer Ribbon for Adhesive Labels 60 mm wide reel 300 m black
Type TT822OUT 60MM
Variant Coloured ribbon
Inside Ø (ID) 25.4mm
Length (L) 300m
Print Method thermal transfer print
Recommended Material

323, 892, 951, 1203, 1204, 1206, 1210, 1211, 1213, 1220, 1221, 1232, 1251

Thickness (T) 6.5µm
Thickness of Foil 4.5
Weight/Unit 0.1kg
Width (W) 60.0mm
CE Certification No
ELV compliant Dir. Art. 4 (2) YES
Hazardous Goods No
Melting Point starting from +110 °C
ROHS compliant Yes
Shelf Life 5 years
Specifications
Specifications ANSI/UL 969
UL Listed (US and Canada) No
UL Listed (US and Canada) No
UL Recognized (US and Canada) No
UL Recognized (US and Canada) No
Country of Origin US
Customs Number 96121010
Dimensions W x H x D 60.0 mm x
GTIN-13 / EAN 4031026210780
Packaging 1 - Height (m) 0.03m
Packaging 1 - Length (m) 0.03m
Packaging 1 - Qty 1
Packaging 1 - Type Reel
Packaging 1 - Volume (m³) 0.00006
Packaging 1 - Weight (kg) 0.163kg
Packaging 1 - Width (m) 0.07m
Reel Length 300m
Reel Length (imperial) 984ft
Storage conditions Maximum 2 years after production date at -5°C to +40°C and 20% to 80% relative humidity.
ETIM 7.0 Key EC000608
ETIM 8.0 Key EC000608
ETIM 9.0 Key EC001694
UNSPSC Key 44103124
