Cable tie outside serrated, 145.0x3.4mm, Ø4.0-35.0mm, beige, 100pcs.
Art.-No. 118-00032 | PT2A-PEEK-BGE Details

  • For high temperature application from -55° C up to +240° C
  • Outside serrated cable tie with smooth surface to the bundle
  • Close-fitting to the cable bundle due to the deepening head shape
  • Easy insertion combined with high tensile strength
  • Takes up less space due to curved head
  • Conjuncts performance of a metal tie with the ease of use of a polyamide cable tie
  • Easy application either manually or with a processing tool
Show more

Request your individual offer now

Application The PEEK Tie has been designed for the Ministry of Defence and Aircraft industry in co-operation with leading companies. With the properties this product claims it is ideal for high temperature applications. This performance will be well appropriate also for the drilling industry, railway, offshore or automotive industry. The PEEK Tie is an extraordinary product. It combines the mechanical performance and resistance to environmental influence of a metal tie with the ease of use of a polyamide cable tie.
Application Tool MK3PNSP2, EVOcut, MK7P, MK10-SB, MK20, EVO7SP, EVO7i, EVO7iSP
Colour Beige (BGE)
Identification Plate Position none
Local order number PT2A.9E3P
Material Polyetheretherketone (PEEK)
Pack Cont. 100pcs.
Package Content packed in Bag
PART DESCRIPTION PT2A-PEEK-BGE
Product Family PEEK Ties, outside serrated
Product Group Cable ties for high temperature applications up to +240 °C
Releasable Closure (Yes/No) No
Short Description PEEK Cable Tie 145x3.4 mm, outside serrated, beige
Tie Closure plastic pawl
Variant Outside Serrated
Bundle Diameter max (metric) 35.0mm
Bundle ∅ 4.0-35.0mm
Bundle ∅ min. 4.0mm
Cable Tie Head Height (metric) 4.5mm
Cable Tie Head Length (metric) 5.7mm
Cable Tie Head Width (metric) 6.1mm
Length (L) 145.0mm
Min.Tensile Strength 230N
Strap Width max. (G) (imperial) 0.24"
Thickness (T) 1.2mm
Weight/Unit 0.000694kg
Width (W) 3.4mm
CE Certification No
CSA Certified No
ELV compliant Dir. Art. 4 (2) YES
Flammability UL 94 V0 (3 mm)
Halogen-free Yes
Hazardous Goods No
Nato number 5975-12-392-1042
Operating Temperature -55 °C to +240 °C
Specifications
Specifications EN 62275, EN 62275:2009, IEC 62275
UL Listed (US and Canada) No
UL Recognized (US and Canada) No
UV-Stabilised No
Country of Origin DE
Customs Number 39269097
GTIN-13 / EAN 4031026252285
Packaging 1 - Height (m) 0.04m
Packaging 1 - Length (m) 0.12m
Packaging 1 - Qty 100
Packaging 1 - Type Bag
Packaging 1 - Volume (m³) 0.00127
Packaging 1 - Weight (kg) 0.074926kg
Packaging 1 - Width (m) 0.265m
Packaging 2 - Height (m) 0.171m
Packaging 2 - Length (m) 0.56m
Packaging 2 - Qty 5000
Packaging 2 - Type Box
Packaging 2 - Volume (m³) 0.0172
Packaging 2 - Weight (kg) 3.9663kg
Packaging 2 - Width (m) 0.18m
Packaging 3 - Height (m) 0.368m
Packaging 3 - Length (m) 0.584m
Packaging 3 - Qty 20000
Packaging 3 - Type Box
Packaging 3 - Volume (m³) 0.083
Packaging 3 - Weight (kg) 16.6852kg
Packaging 3 - Width (m) 0.386m
Packaging 4 - Height (m) 1.248m
Packaging 4 - Length (m) 1.2m
Packaging 4 - Qty 240000
Packaging 4 - Type pallet
Packaging 4 - Volume (m³) 1.198
Packaging 4 - Weight (kg) 222.36kg
Packaging 4 - Width (m) 0.8m
ETIM 7.0 Key EC000046
ETIM 8.0 Key EC000046
ETIM 9.0 Key EC000046
UNSPSC Key 39121703
