Stainless steel cable tie, punch lock, 369x8.9mm, ∅8-100.0mm, metal, 50pcs.
Art.-No. 111-01631 | MST360M-SS304-ML Details

  • MST-Series cable ties are made from stainless steel 304
  • No loosening after bundling
  • Corrosion and weather resistant
  • Significantly improved vibration resistance
  • Outstanding chemical resistance
  • Space saving solution
  • Safe cut-off (no sharp edges)
  • High temperature resistant
  • Non-burning
Show more

Request your individual offer now

Application Stainless steel cable ties are designed for fixing loads and cables securely in hazardous industrial environments such as railway carriages, jet engines, inside power plants or on offshore drilling platforms, where exposure to extremes of weather, saltwater and temperature are common. The MST-Series tie with its new punch-locking mechanism is an excellent choice especially for environments which require high resistance to vibrations.
Application Tool MST9
Colour Metal (ML)
Description Stainless steel tie with a new locking mechanism!
Fixation Method Others
Identification Plate Position none
Key product features vibration absorbing
Local order number MST360M
Material Stainless Steel (SS304)
PART DESCRIPTION MST360M-SS304-ML
Pack Cont. 50pcs.
Package Content packed in Bag
Product Family MST-Series, stainless steel 304
Product Group Cable ties with punch-locking mechanism
Releasable Closure (Yes/No) No
Short Description Stainless Steel Cable Tie with punch-locking mechanism 369x8.9 mm
Tie Closure punch lock
Type MST360M
Variant Not Serrated
Bundle Diameter max (metric) 100.0mm
Bundle ∅ 8-100.0mm
Bundle ∅ min. 8mm
Length (L) 369mm
Min.Tensile Strength 1500N
Thickness (T) 0.3mm
Weight/Unit 0.00543kg
Width (W) 8.9mm
ELV compliant Dir. Art. 4 (2) YES
Halogen-free Yes
Hazardous Goods No
Limited Fire Hazard Yes
Operating Temperature -80 °C to +538 °C
ROHS compliant Yes
Specifications
Specifications IEC 62275 (2006-10)
Country of Origin JP
Customs Number 73269098
GTIN-13 / EAN 4944387109429
Packaging 1 - Height (m) 0.012m
Packaging 1 - Length (m) 0.45m
Packaging 1 - Qty 50
Packaging 1 - Type Bag
Packaging 1 - Volume (m³) 0.00073
Packaging 1 - Weight (kg) 0.271501kg
Packaging 1 - Width (m) 0.135m
Packaging 3 - Height (m) 0.18m
Packaging 3 - Length (m) 0.45m
Packaging 3 - Qty 1500
Packaging 3 - Type Box
Packaging 3 - Volume (m³) 0.0251
Packaging 3 - Weight (kg) 8.35503kg
Packaging 3 - Width (m) 0.31m
Packaging 4 - Height (m) 1.224m
Packaging 4 - Length (m) 1.2m
Packaging 4 - Qty 36000
Packaging 4 - Type pallet
Packaging 4 - Volume (m³) 1.175
Packaging 4 - Weight (kg) 221.52kg
Packaging 4 - Width (m) 0.8m
ETIM 7.0 Key EC000046
ETIM 8.0 Key EC000046
ETIM 9.0 Key EC000046
UNSPSC Key 39121703
