Cable clip for edge
Art.-No. 151-04627
| EC1-3TPDHC6-7-PA66HIRHSUV/MET-BK
Copied
- for one or two solar cables
- secure hold of the cables
- simple change of cables in case of maintenance
- for edges 1.0 - 3.0 mm
Request your individual offer now
Request quote
More products in this product group:
| Application | Our EC1-3SPDHC6-7 will help you lay solar cables. You can easily attach this article to your solar modules in order to guide up to two cables into the holder by simply pressing them in. |
| Cable ⌀ max | 6.8mm |
| Cable ⌀ min | 5.8mm |
| Colour | Black (BK) |
| Fixation Method | EdgeClip, top |
| Key product features | for multiple routing, for direct fixation, for faster processing |
| Material | Polyamide 6.6, high impact modified, heat and UV-stabilised (PA66HIRHSUV), Metal (MET) |
| PART DESCRIPTION | EC1-3TPDHC6-7-PA66HIRHSUV/MET-BK |
| Package Content | 100pcs. |
| Package Content packed in | Bag |
| Product Family | EdgeClip series for solar panels |
| Product Group | Fixing element for solar cables |
| Short Description | EdgeClip for edges 1.0 - 3.0 mm, for parallel routing for up to two solar cables. |
| Type | EC1-3TPDHC6-7 |
| UV-Stabilised | Yes |
| Weight/Unit | 0.00288kg |
Download
|
|
|
| Country of Origin | PL |
| Customs Number | 39269097 |
| GTIN-13 / EAN | 4031026781730 |
| Packaging 1 - Height (m) | 0.04m |
| Packaging 1 - Length (m) | 0.25m |
| Packaging 1 - Qty | 100 |
| Packaging 1 - Type | Bag |
| Packaging 1 - Volume (m³) | 0.00218m³ |
| Packaging 1 - Weight (kg) | 0.297029kg |
| Packaging 1 - Width (m) | 0.218m |
| Packaging 3 - Height (m) | 0.204m |
| Packaging 3 - Length (m) | 0.591m |
| Packaging 3 - Qty | 3000 |
| Packaging 3 - Type | Box |
| Packaging 3 - Volume (m³) | 0.048m³ |
| Packaging 3 - Weight (kg) | 9.87687kg |
| Packaging 3 - Width (m) | 0.398m |
| Packaging 4 - Height (m) | 1.204m |
| Packaging 4 - Length (m) | 1.2m |
| Packaging 4 - Qty | 60000 |
| Packaging 4 - Type | pallet |
| Packaging 4 - Volume (m³) | 1.156m³ |
| Packaging 4 - Weight (kg) | 219.52kg |
| Packaging 4 - Width (m) | 0.8m |
