Self-amalgamating Tapes – Medium Voltage Rubber Tape (Linerless) : HTAPE-POWER715-19x10
Self-amalgamating medium voltage rubber tape 19 mm x 10 m blackArticle number: 711-00311
Features
- Rubber-based self-amalgamating linerless tape
- Used for waterproof sealing and corrosion protection of cables
- Excellent electrical insulation and weather protection
- Time saving application without liner
- The lack of liner causes less waste
- Easy to apply and very flexible
Certifications & Approvals
Application
The rubber-based self-amalgamating linerless tape is used for electrical insulation, protection, sealing, splicing and termination of cables up to 35 kV. The special material comes without a separating liner and reduces therefore the time required to apply the tape. It features with excellent UV, moisture, corrosion, ozone and chemical resistance. HelaTape Power 715 is compatible with all extruded dielectric cable insulations.
More products in this product group
Self-amalgamating Tapes – Medium Voltage Rubber Tape (Linerless) >| Colour | Black (BK) |
| Pack Cont. | 10m |
| Package Quantity per | Reel |
| PART DESCRIPTION | HTAPE-POWER715-19x10-EPR-BK |
| Product Family | HelaTape Power 715 |
| Product Group | Self-amalgamating Tapes – Medium Voltage Rubber Tape (Linerless) |
| Short Description | Self-amalgamating medium voltage rubber tape 19 mm x 10 m black |
| Length (L) | 10m |
| Thickness (T) | 0.5mm |
| Width (W) | 19mm |
| Dielectric Strength | 30 kV/mm |
| Elongation at break | 700 % |
| ELV compliant Dir. Art. 4 (2) | YES |
| Halogenfree | Yes |
| Hazardous good | No |
| Insulating (Yes/No) | Yes |
| Intermittent Operating Temperature | +130°C |
| Material | Ethylene Propylene Rubber (EPR) |
| Operating Temperature - °C | +90 °C |
| Self extinguishing (Yes/No) | Yes |
| Specifications |
|
| Tensile Strength | 2.1N/mm² |
| UV-Resistant (Yes/No) | Yes |
| Volume Resistance | 10¹⁶ Ω cm |
| Water Absorption | 0.06% |
|
|
|
| GTIN-13 / EAN | 4031026573458 |
| Packaging 1 - Height (m) | 0.019m |
| Packaging 1 - Length (m) | 0.09m |
| Packaging 1 - Qty | 1 |
| Packaging 1 - Type | pcs. |
| Packaging 1 - Volume (m³) | 0.00015m³ |
| Packaging 1 - Weight (kg) | 0.117kg |
| Packaging 1 - Width (m) | 0.09m |
| Packaging 3 - Height (m) | 0.175m |
| Packaging 3 - Length (m) | 0.41m |
| Packaging 3 - Qty | 64 |
| Packaging 3 - Type | Carton |
| Packaging 3 - Volume (m³) | 0.0158m³ |
| Packaging 3 - Weight (kg) | 7.977kg |
| Packaging 3 - Width (m) | 0.22m |
| Packaging 4 - Height (m) | 1.195m |
| Packaging 4 - Length (m) | 1.2m |
| Packaging 4 - Qty | 2688 |
| Packaging 4 - Type | pallet |
| Packaging 4 - Volume (m³) | 1.147m³ |
| Packaging 4 - Weight (kg) | 356.044kg |
| Packaging 4 - Width (m) | 0.8m |
| ETIM 6.0 | EC000128 |
| ETIM 7.0 Key | EC000128 |
