FlexiGuard Conduits & Fittings : FG56-PG48

Straight fitting Ø48 PG48-threadArticle number: 167-00517

Features

The fittings for Flexiguard protective hoses are available with PG threads (NV) and metric threads (TV). The fittings are easily fastened to the hoses. The fitting has a long, conical shaped inner socket allowing cables to be protected against liquids and meets IP54. The pins on the inside of the fittings provide a firm hold and prevent slippage of the hose. Due to the reinforced outer walls and the use of modified polypropylene, the NV and TV fittings are especially robust.

Certifications & Approvals

Application

Straight swivel external thread.
Fulfils IP54 with FlexiGuard FG conduits.

Colour Grey (GY)
Pack Cont. 10pcs.
Package Quantity per Bag
PART DESCRIPTION FG56-PG48-PP-GY
Product Family FG-P Fittings
Product Group FlexiGuard Conduits & Fittings
Short Description Straight fitting Ø48 PG48-thread
Type of connection Thread
Variant Straight
A/F Thread (A/F2) 65mm
Diameter (D) 71.0mm
Length (L) 60.0mm
Lowest inner diameter 9mm
Min. Bore Size (B) 45.9mm
Nominal ∅ 56mm
Outside ∅ max (OD max.) 71.0mm
Thread Length (TL) 15.5mm
Thread Size PG48
∅ (D2) 45.9mm
ELV compliant Dir. Art. 4 (2) YES
Flammability UL 94 V2
Halogenfree Yes
Hazardous good No
IP-Rating IP54
Material Polypropylene (PP)
Material of fitting ETIM Polypropylene (PP)
Operating Temperature - °C -35 °C to +80 °C
Specifications
GTIN-13 / EAN 4031026277363
Packaging 1 - Height (m) 0.065m
Packaging 1 - Length (m) 0.3m
Packaging 1 - Qty 10
Packaging 1 - Type Bag
Packaging 1 - Volume (m³) 0.00585
Packaging 1 - Weight (kg) 0.485kg
Packaging 1 - Width (m) 0.3m
Packaging 3 - Height (m) 0.25m
Packaging 3 - Length (m) 0.4m
Packaging 3 - Qty 150
Packaging 3 - Type Carton
Packaging 3 - Volume (m³) 0.04
Packaging 3 - Weight (kg) 7.775kg
Packaging 3 - Width (m) 0.4m
Packaging 4 - Height (m) 1.144m
Packaging 4 - Length (m) 1.2m
Packaging 4 - Qty 3600
Packaging 4 - Type pallet
Packaging 4 - Volume (m³) 1.098
Packaging 4 - Weight (kg) 207.6kg
Packaging 4 - Width (m) 0.8m
ETIM 6.0 EC001178
ETIM 7.0 Key EC001178
