Heat shrinkable tubing 2:1 (19.0/6.4 mm), self extinguishing and overexpanded, black, 60 m reel
Art.-No. 300-73190
| TCN20-19.0/6.4-PO-X-BK
|
Copied
- Thin wall overexpanded polyolefin tubing
- Overexpanded tubes fit more applications (e.g. big cable lugs)
- Self extinguishing and low shrink temperature
- Highly flame-retardant, UL224 VW-1
Request your individual offer now
Request quote
More products in this product group:
| Application | Mechanical and electrical protection applications for parts with high diameter variances. This fast shrinking tubing makes it suitable for high volume production. |
| Colour | Black (BK) |
| Elongation At Heat Aging | 350% |
| Heat Aging Test | 168h/160°C |
| Material | Polyolefin, cross-linked (PO-X) |
| Minimum Tensile Strength At Heat Aging | 14MPa |
| PART DESCRIPTION | TCN20-19.0/6.4-PO-X-BK |
| Package Content | 60m |
| Package Content packed in | Reel |
| Printable | No |
| Product Family | TCN20 overexpanded |
| Product Group | Heat shrinkable tubing 3:1 - Self extinguishing |
| Short Description | Heat shrinkable tubing 2:1 (19.0/6.4 mm), self extinguishing and overexpanded, black, 60 m reel |
| Shrink Ratio | 3:1 |
| Type | TCN20-19.0/6.4 |
| Variant | Thin-Wall |
| Weight/Unit | 0.028kg |
| With inner glue (Yes/No) | No |
Download
| Dielectric Strength | 20kV/mm |
| Dielectric Strength test method | IEC 243 |
| ELV compliant Dir. Art. 4 (2) | YES |
| Elongation at break (min.) | 400% |
| Flammability | UL 224 VW-1 |
| Halogen-free | No |
| Hazardous Goods | No |
| Minimum Shrink Temperature | +100 °C |
| Operating Temperature | -55 °C to +125 °C |
| ROHS compliant | Yes |
| Self extinguishing | Yes |
| Specifications |
|
| Specifications | C22.2 no. 198.1-06, CSA -C22.1, DIN 75200 (09/1980), DIN EN 60068-1/03.95, IEC 60068-1/88 & 92, VW 80000/2009-10 |
| Tensile Strength | 14MPa |
| UL File link | Link Link |
| UL Recognized (US and Canada) | Yes |
| UL Recognized (US) | Yes |
| UL-File Number | E143529 |
| Volume Resistance | 10¹⁴ Ω cm |
| Volume Resistance test method | IEC 93 |
| Country of Origin | CN |
| Customs Number | 39173200 |
| GTIN-13 / EAN | 4031026284729 |
| Packaging 1 - Height (m) | 0.08m |
| Packaging 1 - Length (m) | 0.385m |
| Packaging 1 - Qty | 60 |
| Packaging 1 - Type | Reel |
| Packaging 1 - Volume (m³) | 0.011858m³ |
| Packaging 1 - Weight (kg) | 1.68kg |
| Packaging 1 - Width (m) | 0.385m |
| Packaging 3 - Height (m) | 0.42m |
| Packaging 3 - Length (m) | 0.4m |
| Packaging 3 - Qty | 300 |
| Packaging 3 - Type | Carton |
| Packaging 3 - Volume (m³) | 0.0672m³ |
| Packaging 3 - Weight (kg) | 8.9kg |
| Packaging 3 - Width (m) | 0.4m |
| Packaging 4 - Height (m) | 0.984m |
| Packaging 4 - Length (m) | 1.2m |
| Packaging 4 - Qty | 3600 |
| Packaging 4 - Type | pallet |
| Packaging 4 - Volume (m³) | 0.945m³ |
| Packaging 4 - Weight (kg) | 127.8kg |
| Packaging 4 - Width (m) | 0.8m |
| Reel Length | 60.0m |
