09/08/2025

2-Way Outlet Shapes, VG style
Art.-No. 402-04014 | 204-1-J-PO-X-BK |

Two-way outlet shape 223-2 supplied / fully recovered.

a: Expanded form (supplied)

b: Fully recovered form (after heating)

Mechanical tension relief in cable harnesses

Add to watchlist

Request your individual offer now

Request quote

Distributors near you

More products in this product group:

2-Way Outlet Shapes, VG style >

Base Data

Application	Heat Shrinkable moulded shapes for use in Electrical and Electronic Cable Harness Applications.
Colour	Black (BK)
Local order number	204-1-J
Material	Polyolefin, cross-linked (PO-X)
PART DESCRIPTION	204-1-J-PO-X-BK
Pack Cont.	1pc.
Package Content packed in	Bag
Product Family	Helashrink 200 Series
Product Group	2-Way Outlet Shapes, VG style
Type	204-1-J
Variant	For 2-core cables

Product Dimensions


⌀H max b	18mm
⌀H min a	39mm
⌀J max b	12mm
⌀J min. a	27mm
⌀J/K max. b	12mm
⌀J/K min. a	27mm
⌀K max. b	12mm
⌀K min. a	27mm
Flexibility	Semi rigid
HW ± 30%	3mm
JW nom	2mm
P ± 10%	131mm
P ± 15%=overall length	131.0mm
R nom	66mm
R ± 10%	66mm
S nom	81mm

Downloads

Specifications

Dielectric Strength	15kV/mm
Dielectric Strength test method	ASTM D2671
Flammability	ASTM D635
Minimum Shrink Temperature	+135 °C
Nato number	5970-01-053-0669, 5975-99-254-7300
Operating Temperature	-50 °C to +80 °C
ROHS compliant	Yes
Specifications
UV-Stabilised	No

Logistics and Packaging

Country of Origin	GB
GTIN-13 / EAN	5022660444104

More Information

ETIM 7.0 Key	EC002464
ETIM 8.0 Key	EC002464
ETIM 9.0 Key	EC002464
UNSPSC Key	39121721

Accessories

CHG900 391-90010
Cordless Heat Gun - Gas powered
