1-Piece Fixing Ties with rivet, releasable : RELF170

Fixing tie 180x8 mm, high impact modified, blackArticle number: 115-40902

Features

  • Simple to install with wings to lock ties firmly in place
  • Releasable and reusable
  • RELF and RI ranges are conventional 'serrated' cable ties
  • FBR range has a 'ladder-type' design for a very flexible strap

Certifications & Approvals

Application

Offering a very secure fixing, particularly in applications suffering from vibration, these rivet fixing ties are simple and quick to install. Designed originally for the automotive industry they are now widely used in many industries as diverse as agriculture and ship building.

Application Tool MK6, MK9P, EVO9, EVO9HT
Colour Black (BK)
Fixation Method Rivet Fixing
Identification Plate Position none
Local order number RELF170.IB3P
Pack Cont. 100pcs.
Package Quantity per pcs.
PART DESCRIPTION RELF170-PA66HIR-BK
Product Group 1-Piece Fixing Ties with rivet, releasable
Releasable Closure (Yes/No) Yes
Short Description Fixing tie 180x8 mm, high impact modified, black
Tie Closure plastic pawl
Variant Outside Serrated
Bundle ∅ max. 44.0mm
Bundle ∅ min. 27.0mm
Cable Tie Head Height (metric) 8.0mm
Cable Tie Head Width (metric) 13mm
for Panel Thickness min - max 2.5 - 2.5 mm
Height (H) 18.0mm
Length (L) 180mm
Min.Tensile Strength 225N
Thickness (T) 1.2mm
Width (W) 8.0mm
ELV compliant Dir. Art. 4 (2) YES
Flammability UL 94 HB
Hazardous good No
Material Polyamide 6.6, high impact modified (PA66HIR)
Operating Temperature - °C -40 °C to +80 °C
Specifications
Specifications ANSI/UL 1565, ANSI/UL 62275, ANSI/UL 746B
UL OCD link Link
UL-File Number E64963
GTIN-13 / EAN 5022660138720
Packaging 1 - Height (m) 0.07m
Packaging 1 - Length (m) 0.355m
Packaging 1 - Qty 100
Packaging 1 - Type Bag
Packaging 1 - Volume (m³) 0.00522
Packaging 1 - Weight (kg) 0.288001kg
Packaging 1 - Width (m) 0.21m
Packaging 3 - Height (m) 0.204m
Packaging 3 - Length (m) 0.591m
Packaging 3 - Qty 2000
Packaging 3 - Type Carton
Packaging 3 - Volume (m³) 0.048
Packaging 3 - Weight (kg) 6.56202kg
Packaging 3 - Width (m) 0.398m
Packaging 4 - Height (m) 1.164m
Packaging 4 - Length (m) 1.2m
Packaging 4 - Qty 40000
Packaging 4 - Type pallet
Packaging 4 - Volume (m³) 1.117
Packaging 4 - Weight (kg) 152.24kg
Packaging 4 - Width (m) 0.8m
ETIM 7.0 Key EC000046
