M20 5-9mm Cable Glands
Art.-No. 857-40525 | CG-M20-5-9MM-05 |

M20 Cable Gland.

M20 Cable Gland.

Cable range coverage from 5mm to 9mm
Supplied in multiples of 5
Suitable for use with MDU-S3 and MDU-S5

Add to watchlist

Request your individual offer now

Request quote

Distributors near you

More products in this product group:

M20 5-9mm Cable Glands >

Base Data

Cable ⌀ max	9.0mm
Cable ⌀ min	5.0mm
Colour	Black (BK)
Content	M20 Gland - 5mm - 9mm x 5
Description	M20 5-9mm Cable Glands
PART DESCRIPTION	CG-M20-5-9MM-05
Package Content	5pcs.
Package Content packed in	Bag
Port count	1
Product Family	Fibre Optic Enclosure Accessories
Product Group	M20 5-9mm Cable Glands
Short Description	M20 5-9mm Cable Glands
Technical Description	The cable gland kit consists of 5 x M20 cable glands suitable for use with 5mm to 9mm cables. The cable gland is fitted in to the cable entry port which is secured to the enclosure to provide additional fibre management and support.
Type	CG-M20-5-9MM-05

Specifications

ROHS compliant	Yes
Specifications

Downloads

Logistics and Packaging
More Information

Logistics and Packaging

Country of Origin	GB
GTIN-13 / EAN	5022660164637
Packaging 1 - Height (m)	0.04m
Packaging 1 - Length (m)	0.21m
Packaging 1 - Volume (m³)	0.00126m³
Packaging 1 - Weight (kg)	0.07kg
Packaging 1 - Width (m)	0.15m

More Information

ETIM 7.0 Key	EC000879
ETIM 8.0 Key	EC000879
ETIM 9.0 Key	EC000879
