Cable tie inside serrated, 300x7.6mm, Ø5.0-80.0mm, black, 100pcs.
Art.-No. 111-12210 | T120I-PA66-BK Details

  • Available in a wide range of material and sizes
  • Made from 100% high quality plastic, allows for good recycling
  • Inside serration for a strong hold onto bundles.
  • Easy application either manually or with a processing tool
  • Simply to insert due to bent tail
Show more

Request your individual offer now

e-Learning
Application These cable ties are used for routing, bundling and securing of cables, pipes and hoses.
Application Method Quick, simple fixing by hand or with HellermannTyton tensioning tools
Application Tool ProCut 9 no battery, EVOcut, MK9P, MK9P w/ Upper air, MK10-SB, MK21, EVO9, EVO9SP, EVO9HT, EVO9i, EVO9iSP, EVO9iHT
Colour Black (BK)
Identification Plate Position none
Local order number T120I.NB3P
Material Polyamide 6.6 (PA66)
Pack Cont. 100pcs.
Package Content packed in pcs.
PART DESCRIPTION T120I-PA66-BK
Product Family T-Series in PA66 black
Product Group Cable Ties Polyamide 6.6 standard
Releasable Closure (Yes/No) No
Short Description Cable Tie 300x7.6 mm black
Tie Closure plastic pawl
Variant Inside Serrated
Bundle Diameter max (metric) 80.0mm
Bundle ∅ 5.0-80.0mm
Bundle ∅ min. 5.0mm
Length (L) 300mm
Min.Tensile Strength 535N
Strap Width max. (G) 7.61mm
Strap Width max. (G) (imperial) 0.30"
Thickness (T) 1.6mm
Weight/Unit 0.003kg
Width (W) 7.6mm
ELV compliant Dir. Art. 4 (2) YES
Flammability UL 94 V2
Halogen-free Yes
Hazardous Goods No
Operating Temperature -40 °C to +85 °C, (+105 °C, 500 h)
Specifications
Specifications IEC 60092 series
Country of Origin GB
Customs Number 39269097
GTIN-13 / EAN 5022660019104
Packaging 1 - Height (m) 0.043m
Packaging 1 - Length (m) 0.331m
Packaging 1 - Qty 100
Packaging 1 - Type Bag
Packaging 1 - Volume (m³) 0.00266
Packaging 1 - Weight (kg) 0.300001kg
Packaging 1 - Width (m) 0.187m
Packaging 3 - Height (m) 0.192m
Packaging 3 - Length (m) 0.586m
Packaging 3 - Qty 2000
Packaging 3 - Type Box
Packaging 3 - Volume (m³) 0.0439
Packaging 3 - Weight (kg) 6.80202kg
Packaging 3 - Width (m) 0.39m
Packaging 4 - Height (m) 1.164m
Packaging 4 - Length (m) 1.2m
Packaging 4 - Qty 40000
Packaging 4 - Type pallet
Packaging 4 - Volume (m³) 1.117
Packaging 4 - Weight (kg) 157.04kg
Packaging 4 - Width (m) 0.8m
ETIM 7.0 Key EC000046
ETIM 8.0 Key EC000046
ETIM 9.0 Key EC000046
UNSPSC Key 39121703
