Cable tie inside serrated, 760.0x7.6mm, Ø5.0-225mm, black, 50pcs.
Art.-No. 111-01701 | T120L-PA66W-BK Details

  • Available in a wide range of materials and sizes
  • High tensile strength with very low insertion force
  • Only high quality plastic is used meeting recycling targets
  • Inside serrated cable ties for a strong hold onto bundles
  • Ergonomic bent tail offers quick and simple installation
  • Easy application either manually or with an application tool
Show more

Request your individual offer now

e-Learning
Application These cable ties are used for routing, bundling and securing of cables, pipes and hoses.
Application Method Quick, simple fixing by hand or with HellermannTyton tensioning tools
Application Tool ProCut 9 no battery, EVOcut, MK9P, MK9P w/ Upper air, MK10-SB, MK21, EVO9, EVO9SP, EVO9HT, EVO9i, EVO9iSP, EVO9iHT
Colour Black (BK)
Identification Plate Position none
Local order number T120LRW.WB2P
Material Polyamide 6.6, UV-resistant (PA66W)
PART DESCRIPTION T120L-PA66W-BK
Pack Cont. 50pcs.
Package Content packed in Bag
Product Family T-Series in PA66W black
Product Group Cable Ties for outdoor use (UV-resistant)
Releasable Closure (Yes/No) No
Short Description Cable Tie 760x7.6 mm, UV-resistant, black
Tie Closure plastic pawl
Type T120L
Variant Inside Serrated
Bundle Diameter max (metric) 225mm
Bundle ∅ 5.0-225mm
Bundle ∅ min. 5.0mm
Length (L) 760.0mm
Min.Tensile Strength 535N
Thickness (T) 1.9mm
Weight/Unit 0.01137kg
Width (W) 7.6mm
ELV compliant Dir. Art. 4 (2) YES
Flammability UL 94 V2
Halogen-free Yes
Hazardous Goods No
Nato number 5975-12-337-4659
Operating Temperature -40 °C to +85 °C
ROHS compliant Yes
Specifications
Specifications EN 45545-2, IEC 60092 series, IEC 62275:2006
Country of Origin GB
Customs Number 39269097
GTIN-13 / EAN 5022660344916
Packaging 1 - Height (m) 0.02m
Packaging 1 - Length (m) 0.89m
Packaging 1 - Qty 50
Packaging 1 - Type Bag
Packaging 1 - Volume (m³) 0.00276
Packaging 1 - Weight (kg) 0.568501kg
Packaging 1 - Width (m) 0.155m
Packaging 3 - Height (m) 0.188m
Packaging 3 - Length (m) 0.893m
Packaging 3 - Qty 1000
Packaging 3 - Type Box
Packaging 3 - Volume (m³) 0.0408
Packaging 3 - Weight (kg) 12.05902kg
Packaging 3 - Width (m) 0.243m
Packaging 4 - Height (m) 1.119m
Packaging 4 - Length (m) 1.2m
Packaging 4 - Qty 15000
Packaging 4 - Type pallet
Packaging 4 - Volume (m³) 1.074
Packaging 4 - Weight (kg) 201.885kg
Packaging 4 - Width (m) 0.8m
ETIM 7.0 Key EC000046
ETIM 8.0 Key EC000046
ETIM 9.0 Key EC000046
UNSPSC Key 39121703
