Cable Ties for temperatures up to + 105°C (heat stabilised) T50L

T-Series in PA66HS natural, Article number: 111-05436

Features

  • Heat stabilized cable ties (PA66HS) for temperatures up to +105 °C
  • Available in a wide range of sizes to cover almost every application
  • Inside serration provides a strong hold onto bundles
  • Manual and/or pneumatic tools available for greater process reliability
  • Commonly offered in natural and black, other colors available on request

Certifications & Approvals

Application

These inside serrated cable ties are made from heat stabilized Polyamide 6.6 (PA66HS). They can be applied in environments with continuous temperatures up to +105 °C. T-Series cable ties can be easily installed by hand or using an application tool to ensure consistency of installation.

T-Series in PA66HS natural is suitable for following markets and industries

Application Tool MK3PNSP2, MK3SP, MK6, MK7HT, MK7P, MK20, MK21, EVO7, EVO9
Colour Natural (NA)
Description Short (BMEcat) (max. 150 characters) Cable Tie 390x4.6 HS-black
Identification Plate Position none
Pack Cont. 100pcs.
Package Quantity per Bag
PART DESCRIPTION T50L-PA66HS-NA
Product Family T-Series in PA66HS natural
Product Group Cable Ties for temperatures up to + 105°C (heat stabilised)
Releasable Closure (Yes/No) No
Tie Closure plastic pawl
Type T50L.HN3P
Variant Inside Serrated
Bundle ∅ max. 110mm
Bundle ∅ min. 1.5mm
Length (L) 390.0mm
Min.Tensile Strength 225N
Thickness (T) 1.4mm
Width (W) 4.6mm
ELV compliant Dir. Art. 4 (2) YES
Flammability UL 94 V2
Halogenfree Yes
Hazardous good No
Material Polyamide 6.6, heat stabilised (PA66HS)
Operating Temperature - °C -40 °C to +105 °C, (+145 °C, 500 h)
Specifications
Specifications ANSI/UL 1565, ANSI/UL 62275, ANSI/UL 746B, IEC 60092 series, IEC 62275:2006
UL Type 11
UL-File Number E64963
EAN / GTIN 5022660322341
Packaging 1 - Height (m) 0.04m
Packaging 1 - Length (m) 0.516m
Packaging 1 - Qty 100
Packaging 1 - Type Bag
Packaging 1 - Volume (m³) 0.00324
Packaging 1 - Weight (kg) 0.27kg
Packaging 1 - Width (m) 0.157m
Packaging 3 - Height (m) 0.204m
Packaging 3 - Length (m) 0.591m
Packaging 3 - Qty 4000
Packaging 3 - Type Carton
Packaging 3 - Volume (m³) 0.048
Packaging 3 - Weight (kg) 11.602kg
Packaging 3 - Width (m) 0.398m
Packaging 4 - Height (m) 1.164m
Packaging 4 - Length (m) 1.2m
Packaging 4 - Qty 80000
Packaging 4 - Type pallet
Packaging 4 - Volume (m³) 1.117
Packaging 4 - Weight (kg) 253.04kg
Packaging 4 - Width (m) 0.8m
Weight 0.27kg
ETIM 6.0 EC000046
ETIM 7.0 Key EC000046
