Metal Banding for Heavy Duty Application : AMT5L16SB
Stainless Steel Cable Tie 500x16 mm, Article number: 111-00327
Features
- AMT ties for heavy-duty application
- Available in type 316 stainless steel
- Suitable for applications with high vibrations
Certifications & Approvals
Application
The AMT tie is designed for heavy duty applications. The folding mechanism ensures that the tie will not become loose under vibration. Therefore in all safety relevant areas where vibration is normal, such as in the rail, ship or construction industry, this product is ideal.
AMT-Series, Stainless Steel 316 is suitable for following markets and industries
More products in this product group
Metal Banding for Heavy Duty Application >| Application Tool | HDT16 |
| Colour | Metal (ML) |
| Identification Plate Position | none |
| Pack Cont. | 10pcs. |
| Package Quantity per | Bag |
| PART DESCRIPTION | AMT5L16SB-SS316-ML |
| Product Family | AMT-Series, Stainless Steel 316 |
| Product Group | Metal Banding for Heavy Duty Application |
| Releasable Closure (Yes/No) | No |
| Short Description | Stainless Steel Cable Tie 500x16 mm |
| Tie Closure | folding |
| Type | 111-00327 |
| Variant | Extended Length |
|
|
|
| Bundle ∅ max. | 110mm |
| Length (L) | 500mm |
| Min.Tensile Strength | 2500N |
| Thickness (T) | 0.4mm |
| Width (W) | 16.0mm |
| ELV compliant Dir. Art. 4 (2) | YES |
| Flammability | Non burning |
| Halogenfree | Yes |
| Hazardous good | No |
| Limited Fire Hazard | Yes |
| Material | Stainless Steel (SS316) |
| Operating Temperature - °C | -80 °C to +538 °C |
| Specifications |
|
|
|
|
| EAN / GTIN | 5022660300103 |
| Packaging 1 - Height (m) | 0.035m |
| Packaging 1 - Length (m) | 0.6m |
| Packaging 1 - Qty | 10 |
| Packaging 1 - Type | Bag |
| Packaging 1 - Volume (m³) | 0.0021m³ |
| Packaging 1 - Weight (kg) | 0.390001kg |
| Packaging 1 - Width (m) | 0.1m |
| Packaging 3 - Height (m) | 0.135m |
| Packaging 3 - Length (m) | 0.6m |
| Packaging 3 - Qty | 200 |
| Packaging 3 - Type | Carton |
| Packaging 3 - Volume (m³) | 0.0219m³ |
| Packaging 3 - Weight (kg) | 8.3kg |
| Packaging 3 - Width (m) | 0.27m |
| Packaging 4 - Height (m) | 1.225m |
| Packaging 4 - Length (m) | 1.2m |
| Packaging 4 - Qty | 6400 |
| Packaging 4 - Type | pallet |
| Packaging 4 - Volume (m³) | 1.176m³ |
| Packaging 4 - Weight (kg) | 286.6kg |
| Packaging 4 - Width (m) | 0.8m |
| Weight | 0.39kg |
| ETIM 6.0 | EC000046 |
| ETIM 7.0 Key | EC000046 |
