Cable clip for adhesive use/with pipe/tube holder, Dmax=6.0mm, natural, 500pcs.
Art.-No. 151-13403 | RA6-PA66-NA Details

  • One-piece self adhesive mount for quick and easy installation
  • Can be used without cable ties offering process optimization
  • Designed to hold wires, cables or hoses
  • Different sizes for various bundle diameters available
  • Two types of adhesive can be offered
Show more
Package size

Request your individual offer now

Application These mounts are ideal for use in applications which are difficult to access or for areas where self adhesive is the only possible fixing method and fixing holes would be unacceptable. The self adhesive mounts can be used without cable ties. Offering process optimization in industries like automotive, bus and truck, construction vehicles or industrial building.
Colour Natural (NA)
Fixation Method Pasting / Stick
Local order number RA6.NN6P
Material Polyamide 6.6 (PA66)
PART DESCRIPTION RA6-PA66-NA
Pack Cont. 500pcs.
Package Content packed in Bag
Product Family RA-Series
Product Group Mounts with cable clip, self-adhesive
Type RA6
Variant Closed
Bundle Diameter max (metric) 6.0mm
Bundle ∅ 6.0mm
Height (H) 9.0mm
Length (L) 19.0mm
Nominal ∅ 6mm
Width (W) 19.0mm
Width (W2) 5.0mm
Adhesive Synthetic rubber with base of polyethylene foam
Adhesive Operating Temperature -40 °C to +60 °C
Flammability UL 94 V2 (excluding adhesive)
Operating Temperature -40 °C to +85 °C
ROHS compliant Yes
Specifications
UV-Stabilised No
Country of Origin GB
GTIN-13 / EAN 5022660314612
Packaging 1 - Weight (kg) 3kg
ETIM 7.0 Key EC000127
ETIM 8.0 Key EC000127
ETIM 9.0 Key EC000127
UNSPSC Key 39121702
