Label, white, thermal transfer print, 20.00x96.00mm, 2500pcs.
Art.-No. 596-12146 | TAG140TD1-1210-WH Details

  • Suited to slightly rough surfaces such as computer panels
  • Adheres to rounded surfaces
  • TAG140TD1 is two-part asset tracking label. The label is perforated 60mm from the left edge allowing one part to be fixed onto the asset and the other retained by the user.

Request your individual offer now

Application The specially formulated adhesive labels give the highest quality print clarity when printed on thermal transfer printers. The range of materials and ribbons have been developed to suit the needs of most users. Designing and printing labels is simple and users can quickly print out professional labels in a matter of moments when using TagPrint Pro labelling software.
Application Method The functionality and durability of the labels can be negatively affected if improperly processed or applied. All surfaces to be bonded must be clean, dry as well as free from dust and grease. Avoid touching the adhesive surface of the label as this could impair the application performance.
Chem. Material Properties Resistant to water, alcohol, most oils, greases, fuel, aliphatic solvents, weak acids, salts and alkalis.
Colour White (WH)
Colour Marking Field White gloss (GSWH)
Local order number TAG143TD1-1210
Material Type 1210, Vinyl, white gloss (1210)
Mech. Material Properties permanent adhesive, suitable for critical surfaces
PART DESCRIPTION TAG140TD1-1210-WH
Pack Cont. 2500pcs.
Package Content packed in Reel
Product Family Material 1210 (White), for rough surfaces
Product Group Component labelling, thermal transfer
Self adhesive (Yes/No) Yes
Short Description Component Labelling for Thermal Transfer Printer 96x20 mm white
Type TAG140TD1
Height (H) 20.00mm
Print Method thermal transfer print
Thickness of Foil 84
Thickness of foil test method ISO 534
VR 22.96mm
Weight/Unit 0.000397kg
Width (W) 96.00mm
Width of Liner (WL) 100.00mm
Adhesive Acrylic
Curing Temperature from +5 °C
ELV compliant Dir. Art. 4 (2) YES
Halogen-free No
Hazardous Goods No
Initial tack 11N/25 mm
Initial tack FINAT FTM 9
Operating Temperature -20 °C to +80 °C
Peel strength 250 N/m
Peel strength test method FINAT FTM 2
Pre-Printed No
ROHS compliant Yes
Recommended Ribbon Type TT822OUT
Shelf Life Minimum 1 year upon receipt / maximal 2 years after production date.
Specifications
Country of Origin DE
Customs Number 39199080
GTIN-13 / EAN 4031026296227
Labels per Row 1pc.
Packaging 1 - Height (m) 0.117m
Packaging 1 - Length (m) 0.147m
Packaging 1 - Qty 2500
Packaging 1 - Type Reel
Packaging 1 - Volume (m³) 0.00253
Packaging 1 - Weight (kg) 0.993kg
Packaging 1 - Width (m) 0.147m
Packaging 2 - Height (m) 0.12m
Packaging 2 - Length (m) 0.156m
Packaging 2 - Qty 2500
Packaging 2 - Type Carton
Packaging 2 - Volume (m³) 0.0028
Packaging 2 - Weight (kg) 1.093kg
Packaging 2 - Width (m) 0.15m
Packaging 4 - Length (m) 1.2m
Packaging 4 - Type pallet
Packaging 4 - Width (m) 0.8m
Storage Temperature +21 °C
Storage conditions 50% relative humidity., The storage in the original packaging is recommended., Please avoid warehousing under impacts such as high humidity, heat and coldness.
ETIM 7.0 Key EC001288
ETIM 8.0 Key EC001288
ETIM 9.0 Key EC001288
UNSPSC Key 39121702
