Label, white, thermal transfer print, 36.50x88.90mm, 1000pcs.
Art.-No. 596-12664 | TAG64TD1-1206-WH Details

  • Ideal for machinery operating in high temperature areas (up to +150 °C)
  • For applications on flat surfaces
  • Chemical resistant polyester foil
  • For permanent and ageing-resistant identification
  • Barcodes and alphanumeric text remain pin sharp on this high quality material
Show more

Request your individual offer now

e-Learning
Application This label is scratch-resistant and is ideal for usage as identification or name plate in industrial environments. The high temperature range suits a wide range of applications on flat surfaces. The adhesive is also suitable for critical surfaces like plastic and paint. Designing and printing labels is simple and users can quickly print out professional labels in a matter of moments when using TagPrint Pro labelling software.
Application Method The functionality and durability of the labels can be negatively affected if improperly processed or applied. All surfaces to be bonded must be clean, dry as well as free from dust and grease. Avoid touching the adhesive surface of the label as this could impair the application performance.
Chem. Material Properties Excellent resistance to water, alcohol, most oils, greases, fuel, aliphatic solvents, weak acids, salts and alkalis.
Colour White gloss (GSWH)
Local order number TAG64TD1-1206-WH
Material Type 1206, Polyester (1206)
Mech. Material Properties permanent adhesive, suitable for critical surfaces
PART DESCRIPTION TAG64TD1-1206-WH
Pack Cont. 1000pcs.
Package Content packed in Reel
Product Family Material 1206 (White)
Product Group Asset identification label, thermal transfer
Self adhesive (Yes/No) Yes
Short Description Asset Identification Label for Thermal Transfer Printing 88.9x36.5 mm white
Type TAG64TD1
Height (H) 36.50mm
Print Method thermal transfer print
Print Method (Alternative) laser beam print
Thickness of Foil 50
Thickness of foil test method ISO 534
VR 40.64mm
Weight/Unit 0.000684kg
Width (W) 88.90mm
Width of Liner (WL) 95.00mm
Adhesive Acrylic
Curing Temperature from 0 °C
ELV compliant Dir. Art. 4 (2) YES
Halogen-free Yes
Hazardous Goods No
Initial tack 13N
Initial tack FINAT FTM 9
Operating Temperature -40 °C to +150 °C
Pre-Printed No
ROHS compliant Yes
Recommended Ribbon Type TT822OUT
Shear strength 1000min
Shear strength test method FINAT FTM 8
Shelf Life Minimum 1 year upon receipt / maximal 4 years after production date.
Specifications
UL Recognized (US and Canada) Yes
Country of Origin DE
Customs Number 39199080
GTIN-13 / EAN 4031026296562
Labels per Row 1pc.
Packaging 1 - Height (m) 0.116m
Packaging 1 - Length (m) 0.15m
Packaging 1 - Qty 1000
Packaging 1 - Type Bag
Packaging 1 - Volume (m³) 0.00271
Packaging 1 - Weight (kg) 0.684001kg
Packaging 1 - Width (m) 0.156m
Storage Temperature +15 °C to +25 °C
Storage conditions 45% ±5% relative humidity., The storage in the original packaging is recommended., Please avoid warehousing under impacts such as high humidity, heat and coldness., Must be stored in a dark place.
ETIM 7.0 Key EC001288
ETIM 8.0 Key EC001288
ETIM 9.0 Key EC001288
UNSPSC Key 39121702
