2-Piece Fixing Ties with Fir Tree, with Disc, for Round Holes : T120IFT9

2-Piece fixing tie 150x4.6 mm, with fir tree, PA66HS/PA66HIRHS, blackArticle number: 156-00200

Features

  • Pre-assembled 2-piece fixing tie with fir tree foot part
  • Cable tie head can be moved after bundling
  • Easy to assemble without the need for a tool
  • Disc adjusts tie for pressure from various directions and minimises access of dust and dirt
  • Fir tree foot part can be used for a variety of panel thicknesses
  • Suitable for use within threaded holes

Certifications & Approvals

Application

Primarily designed for fixing cable harnesses in the automotive industry their simplicity, and ease of use, has seen these parts used in everything from aircraft, to switch-gear, to washing machines.

Application Tool MK6, MK9P, MK21, EVO9, EVO9HT
Colour Black (BK)
Fixation Method Fir Tree
Identification Plate Position none
Local order number T120IFT9.SB3E
Pack Cont. 100pcs.
Package Quantity per Carton
PART DESCRIPTION T120IFT9-PA66HIR(S)-BK
Product Family Fir Tree Parts FT9
Product Group 2-Piece Fixing Ties with Fir Tree, with Disc, for Round Holes
Short Description 2-Piece fixing tie 150x4.6 mm, with fir tree, PA66HS/PA66HIRHS, black
Tie Closure plastic pawl
Variant Inside Serrated
Bundle ∅ max. 80.0mm
Bundle ∅ min. 8.0mm
Disc ∅ 20.0mm
for Hole ∅ (FH) 9.0 - 10.6 mm
for Panel Thickness min - max 5 - 11 mm
Height (H) 1.6mm
Height (H2) 18.8mm
Length (L) 300mm
Length (L2) 15.0mm
Min.Tensile Strength 535N
Panel Thickness max. 5.0 - 11. 0mm
Width (W) 7.6mm
Width (W2) 15.0mm
ELV compliant Dir. Art. 4 (2) YES
Flammability UL 94 HB
Halogenfree Yes
Hazardous good No
Material Polyamide 6.6, high impact modified, scan black (PA66HIR(S))
Operating Temperature - °C -40 °C to +80 °C, (+105 °C, 500 h)
Specifications
GTIN-13 / EAN 5022660318337
Packaging 1 - Height (m) 0.15m
Packaging 1 - Length (m) 0.4m
Packaging 1 - Qty 100
Packaging 1 - Type Bag
Packaging 1 - Volume (m³) 0.018
Packaging 1 - Weight (kg) 0.606993kg
Packaging 1 - Width (m) 0.3m
Packaging 3 - Height (m) 0.368m
Packaging 3 - Length (m) 0.584m
Packaging 3 - Qty 1500
Packaging 3 - Type Carton
Packaging 3 - Volume (m³) 0.083
Packaging 3 - Weight (kg) 9.924895kg
Packaging 3 - Width (m) 0.386m
Packaging 4 - Height (m) 1.248m
Packaging 4 - Length (m) 1.2m
Packaging 4 - Qty 18000
Packaging 4 - Type pallet
Packaging 4 - Volume (m³) 1.198
Packaging 4 - Weight (kg) 140.1kg
Packaging 4 - Width (m) 0.8m
ETIM 7.0 Key EC000046
