Screw fixing mounts : CTM0
Cable Tie Mount with curved design 14.7x9.4 mm black, Article number: 151-30303
Features
- Curved design for additional cable support
- Simple to install with a screw or bolt
- Excellent security, particularly in areas of high vibration
- Mounts are available in various sizes and materials
Certifications & Approvals
Application
Designed specifically for holding heavier cable bundles these mounting bases can be used in many industries from agriculture to truck manufacture, they offer a very secure fixing and can be used with a wide variety of heavy duty cable ties up to 7.9 mm wide.
More products in this product group
Screw fixing mounts >| Colour | White (WH) |
| Fixation Method | Screw Mounting and Rivet |
| Mounting Screw Type | #6 (M3) Screw |
| Pack Cont. | 100pcs. |
| Package Quantity per | Bag |
| PART DESCRIPTION | CTM0-PA66-WH |
| Product Family | Cable tie mounts with curved design |
| Product Group | Screw fixing mounts |
| Short Description | Cable Tie Mount with curved design 14.7x9.4 mm black |
| Type | CTM0.NW3P |
|
|
|
| for Hole ∅ (FH) | 3.8 mm |
| Height (H) | 6.90mm |
| Length (L) | 14.7mm |
| Strap Width max. (G) | 5.0mm |
| Strap Width max. (G) (imperial) | 0.2" |
| Width (W) | 9.4mm |
| CE Certification | Yes |
| CSA Certified | No |
| ELV compliant Dir. Art. 4 (2) | YES |
| Flammability | UL 94 V2 |
| Hazardous good | No |
| Material | Polyamide 6.6 (PA66) |
| Operating Temperature - °C | -40 °C to +85 °C |
| Prop65 Warning | No |
| Specifications |
|
| Specifications | ANSI/UL 1565, ANSI/UL 62275, ANSI/UL 746B |
| UL Listed (US and Canada) | No |
| UL Recognized (US and Canada) | Yes |
| UL-File Number | E64139 |
|
|
|
| EAN / GTIN | 4031026312538 |
| Packaging 1 - Height (m) | 0.0775m |
| Packaging 1 - Length (m) | 0.2m |
| Packaging 1 - Qty | 100 |
| Packaging 1 - Type | Bag |
| Packaging 1 - Volume (m³) | 0.0019m³ |
| Packaging 1 - Weight (kg) | 0.050001kg |
| Packaging 1 - Width (m) | 0.1225m |
| Packaging 3 - Height (m) | 0.215m |
| Packaging 3 - Length (m) | 0.512m |
| Packaging 3 - Qty | 15000 |
| Packaging 3 - Type | Carton |
| Packaging 3 - Volume (m³) | 0.0347m³ |
| Packaging 3 - Weight (kg) | 8.11015kg |
| Packaging 3 - Width (m) | 0.315m |
| Packaging 4 - Height (m) | 1.219m |
| Packaging 4 - Length (m) | 1.2m |
| Packaging 4 - Qty | 300000 |
| Packaging 4 - Type | pallet |
| Packaging 4 - Volume (m³) | 1.17m³ |
| Packaging 4 - Weight (kg) | 183.2kg |
| Packaging 4 - Width (m) | 0.8m |
| Weight | 0.05kg |
| ETIM 6.0 | EC000449 |
| ETIM 7.0 Key | EC000449 |
| UNSPSC Key | 39121717 |
