Cable Ties for parallel routing T50RDH

DH-Series, Article number: 117-05002

Features

  • Possibility to separate bundles with only one cable tie
  • Cable tie with two heads creating an inside and outside serrated loop
  • Available in a wide range of materials
  • Bundles can be of different diameter
  • Maximum bundle diameter is a maximum combined bundle
  • Easy application either manually or with a processing tool

Certifications & Approvals

Application

Double loop head ties are ideal for separation of two cable runs without the need for additional cable ties. Additionally these ties are widely used within the packaging industry. The first loop closes and secures the bag whilst the second loop can be made into a carrying handle (subject to weight).

DH-Series is suitable for following markets and industries

Application Tool MK3PNSP2, MK3SP, MK7P, MK20, EVO7
Colour Natural (NA)
Description Short (BMEcat) (max. 150 characters) Two Head Cable Tie 210x4.7 mm PA66 natural
GLOBAL PART DESCRIPTION T50RDH-PA66-NA
Identification Plate Position none
Pack Cont. 100pcs.
Package Quantity per Bag
Product Family DH-Series
Product Group Cable Ties for parallel routing
Releasable Closure (Yes/No) No
Tie Closure plastic pawl
Type T50RDH.NN3P
Variant Inside Serrated
Bundle ∅ max. 38.0mm
Bundle ∅ min. 1.6mm
Length (L) 210mm
Min. Tensile Strength 2nd loop 180N
Min.Tensile Strength 225N
Thickness (T) 1.4mm
Width (W) 4.7mm
ELV compliant Dir. Art. 4 (2) YES
Flammability UL 94 V2
Halogenfree Yes
Hazardous good No
Material Polyamide 6.6 (PA66)
Operating Temperature - °C -40 °C to +85 °C
Specifications
Specifications ANSI/UL 1565, ANSI/UL 62275, ANSI/UL 746B
UL-File Number E64963
EAN / GTIN 5022660324369
Packaging 1 - Height (m) 0.03m
Packaging 1 - Length (m) 0.33m
Packaging 1 - Qty 100
Packaging 1 - Type Bag
Packaging 1 - Volume (m³) 0.00144
Packaging 1 - Weight (kg) 0.165kg
Packaging 1 - Width (m) 0.145m
Packaging 3 - Height (m) 0.204m
Packaging 3 - Length (m) 0.591m
Packaging 3 - Qty 6000
Packaging 3 - Type Carton
Packaging 3 - Volume (m³) 0.048
Packaging 3 - Weight (kg) 10.672kg
Packaging 3 - Width (m) 0.398m
Packaging 4 - Height (m) 1.164m
Packaging 4 - Length (m) 1.2m
Packaging 4 - Qty 120000
Packaging 4 - Type pallet
Packaging 4 - Volume (m³) 1.117
Packaging 4 - Weight (kg) 234.44kg
Packaging 4 - Width (m) 0.8m
Weight 0.165kg
ETIM 5.0 EC000046
ETIM 6.0 EC000046
