28/05/2024

Cable tie inside serrated for multiple routing, 210x4.7mm, Ø1.6-38.0mm, black, 100pcs.
Art.-No. 117-05050 | T50RDH-PA66HS-BK Details

  • Possibility to separate bundles with only one cable tie
  • Cable tie with two heads creating an inside and outside serrated loop
  • Available in a wide range of materials
  • Bundles can be of different diameter
  • Maximum bundle diameter is a maximum combined bundle
  • Easy application either manually or with a processing tool
Show more

Request your individual offer now

e-Learning
Application Double loop head ties are ideal for separation of two cable runs without the need for additional cable ties. Additionally these ties are widely used within the packaging industry. The first loop closes and secures the bag whilst the second loop can be made into a carrying handle (subject to weight).
Application Tool ProCut 9 no battery, MK3PNSP2, EVOcut, MK7P, MK10-SB, MK20, EVO7, EVO7SP, EVO7i, EVO7iSP, EVO9, EVO9SP, EVO9i, EVO9iSP
Colour Black (BK)
Identification Plate Position none
Key product features for multiple routing
Local order number T50RDH.HB3P
Material Polyamide 6.6, heat stabilised (PA66HS)
PART DESCRIPTION T50RDH-PA66HS-BK
Pack Cont. 100pcs.
Package Content packed in pcs.
Product Family DH-Series
Product Group Cable ties for parallel routing
Releasable Closure (Yes/No) No
Short Description Two Head Cable Tie 210x4.7 mm PA66HS black
Tie Closure plastic pawl
Type T50RDH
Variant Inside Serrated
Bundle Diameter max (metric) 38.0mm
Bundle ∅ 1.6-38.0mm
Bundle ∅ min. 1.6mm
Length (L) 210mm
Min. Tensile Strength 2nd loop 180N
Min.Tensile Strength 225N
Thickness (T) 1.4mm
Weight/Unit 0.00168kg
Width (W) 4.7mm
ELV compliant Dir. Art. 4 (2) YES
Flammability UL 94 V2
Halogen-free Yes
Hazardous Goods No
Operating Temperature -40 °C to +105 °C, (+145 °C, 500 h)
ROHS compliant Yes
Specifications
Specifications csa-C22.2 no. 62275
UL OCD link Link
UL Recognized (US and Canada) Yes
UL-File Number E64963
Country of Origin GB
Customs Number 39269097
GTIN-13 / EAN 5022660324314
Packaging 1 - Height (m) 0.025m
Packaging 1 - Length (m) 0.325m
Packaging 1 - Qty 100
Packaging 1 - Type Bag
Packaging 1 - Volume (m³) 0.00122
Packaging 1 - Weight (kg) 0.168001kg
Packaging 1 - Width (m) 0.15m
Packaging 3 - Height (m) 0.192m
Packaging 3 - Length (m) 0.586m
Packaging 3 - Qty 6000
Packaging 3 - Type Box
Packaging 3 - Volume (m³) 0.0439
Packaging 3 - Weight (kg) 10.88206kg
Packaging 3 - Width (m) 0.39m
Packaging 4 - Height (m) 1.164m
Packaging 4 - Length (m) 1.2m
Packaging 4 - Qty 120000
Packaging 4 - Type pallet
Packaging 4 - Volume (m³) 1.117
Packaging 4 - Weight (kg) 238.64kg
Packaging 4 - Width (m) 0.8m
ETIM 7.0 Key EC000046
ETIM 8.0 Key EC000046
ETIM 9.0 Key EC000046
UNSPSC Key 39121703
