Cable tie outside serrated, 245x4.6mm, ∅1.6-66.0mm, natural, 100pcs.
Art.-No. 118-00055 | T50MOS-PA66HS-NA Details

  • Outside serrated cable tie with smooth surface to the bundle
  • Tie follows the contours of the cable bundle perfectly
  • Takes up less space due to curved head design
  • Easy insertion combined with high tensile strength
  • PA46 material for higher temperatures up to +195 °C (500 h)
  • PA66V0 cable ties fulfill Limited Fire Hazard requirements
  • Easy application either manually or with a processing tool
Show more

Request your individual offer now

Application OS-Series cable ties are used in many areas where thin-walled or soft insulation wires and cable are being installed, for instance automotive and aircraft industry. OS ties manufactured from PA66V0 material are suitable for applications where safety regulations require reduction of smoke and dangerous gases.
Colour Natural (NA)
Identification Plate Position none
Local order number T50MOS.HN3P
Material Polyamide 6.6, heat stabilised (PA66HS)
PART DESCRIPTION T50MOS-PA66HS-NA
Pack Cont. 100pcs.
Package Content packed in Bag
Product Family OS-Series
Product Group Cable ties for thin-walled bundles
Releasable Closure (Yes/No) No
Short Description Cable Tie outside serrated 245x4.6 mm, heat stabilised, natural
Tie Closure plastic pawl
Type T50MOS
Variant Outside Serrated
Bundle Diameter max (metric) 66.0mm
Bundle ∅ 1.6-66.0mm
Bundle ∅ min. 1.6mm
Height (H) 1.3mm
Length (L) 245mm
Min.Tensile Strength 225N
Thickness (T) 1.3mm
Weight/Unit 0.0007kg
Width (W) 4.6mm
ELV compliant Dir. Art. 4 (2) YES
Flammability UL 94 V2
Halogen-free Yes
Hazardous Goods No
Operating Temperature -40 °C to +105 °C, (+105 °C for 500 h)
ROHS compliant Yes
Specifications
Country of Origin GB
Customs Number 39269097
GTIN-13 / EAN 5022660181719
Packaging 1 - Height (m) 0.032m
Packaging 1 - Length (m) 0.278m
Packaging 1 - Qty 100
Packaging 1 - Type Bag
Packaging 1 - Volume (m³) 0.00094
Packaging 1 - Weight (kg) 0.070001kg
Packaging 1 - Width (m) 0.106m
Packaging 3 - Height (m) 0.345m
Packaging 3 - Length (m) 0.38m
Packaging 3 - Qty 6000
Packaging 3 - Type Box
Packaging 3 - Volume (m³) 0.0498
Packaging 3 - Weight (kg) 4.82006kg
Packaging 3 - Width (m) 0.38m
Packaging 4 - Height (m) 1.179m
Packaging 4 - Length (m) 1.2m
Packaging 4 - Qty 108000
Packaging 4 - Type pallet
Packaging 4 - Volume (m³) 1.132
Packaging 4 - Weight (kg) 107.76kg
Packaging 4 - Width (m) 0.8m
ETIM 7.0 Key EC000046
ETIM 8.0 Key EC000046
ETIM 9.0 Key EC000046
UNSPSC Key 39121703
