15/05/2021

Edge protection for cut-out sections : G51TA

Edge protection 0.4-1.3 mm, PTFE, natural, 3 m reelArticle number: 251-30109

Features

  • Very flexible
  • Easily and securely applied without adhesives
  • Close-fitting rail for effective, orderly-looking protection
  • Excellent resistance to high temperatures and most chemicals

Certifications & Approvals

Application

Flexiform grommet strips are used to protect cables and wires routed through sharp-edged cutout sections.

Colour Natural (NA)
Local order number G51TA
Pack Cont. 3m
Package Quantity per Reel
PART DESCRIPTION G51TA-PTFE-NA
Product Family Flexiform G51T PTFE grommet strip
Product Group Edge protection for cut-out sections
Short Description Edge protection 0.4-1.3 mm, PTFE, natural, 3 m reel
Variant Open
for Panel Thickness min - max 0.4 - 1.3 mm
for Panel Thickness min - max 0 - 0.1 "
Height (H) 4.3mm
Height (H2) 2.7mm
Width (W) 3.9mm
Width (W2) 1.5mm
CSA Certified No
ELV compliant Dir. Art. 4 (2) YES
Flammability UL 94 V0
Halogenfree No
Hazardous good No
Material Polytetrafluoroethylene (PTFE)
Nato number 9390-12-182-1607
Operating Temperature - °C -60 °C to +260 °C, intermittent +350 °C
Specifications
UL Listed (US and Canada) No
UL Recognized (US and Canada) No
US Gov. Designation MS21266-1T
GTIN-13 / EAN 5022660486166
Packaging 1 - Height (m) 0.02m
Packaging 1 - Length (m) 0.148m
Packaging 1 - Qty 3
Packaging 1 - Type Reel
Packaging 1 - Volume (m³) 0.00044
Packaging 1 - Weight (kg) 0.06kg
Packaging 1 - Width (m) 0.148m
Packaging 2 - Height (m) 0.035m
Packaging 2 - Length (m) 0.158m
Packaging 2 - Qty 3
Packaging 2 - Type Carton
Packaging 2 - Volume (m³) 0.0008
Packaging 2 - Weight (kg) 0.56kg
Packaging 2 - Width (m) 0.145m
Reel Length (imperial) 9.7ft
ETIM 6.0 EC001937
ETIM 7.0 Key EC001937
UNSPSC Key 39131603
