Fixing tie for hole (round), not serrated, Ø9.0-27.0mm, black, 500pcs.
Art.-No. 150-26100 | FBS100-PA66-BK Details

This product is not available anymore.
  • Easy to assemble without the need for a tool
  • Cable tie head always situated in defined position
  • Arrowhead simply locks into place
  • Supporting legs provide a secure and firm fixing in areas where space is limited
  • Releasable and therefor reusable
Show more

Request your individual offer now

Application With a diverse range of fixing possibilities are ideal for use in many different industries, including automotive, aerospace and panel building.
Colour Black (BK)
Fixation Method arrowhead
Identification Plate Position none
Key product features releasable
Local order number FBS100.NB6P
Material Polyamide 6.6 (PA66)
Pack Cont. 500pcs.
Package Content packed in Bag
PART DESCRIPTION FBS100-PA66-BK
Product Family for round holes, releasable
Product Group 1-Piece Fixing Ties with Arrowhead, with Wings, releasable
Releasable Closure (Yes/No) Yes
Short Description Fixing Tie 115x10.0 black
Tie Closure ladder style
Variant Not Serrated
Bundle Diameter max (Metric) 27.0mm
Bundle ∅ 9.0-27.0mm
Bundle ∅ min. 9.0mm
for Hole ∅ (FH) 5.9 - 6.7 mm
for Panel Thickness min - max 0.7 - 3 mm
for Panel Thickness min - max 0 - 0.2 "
Length (L) 114.5mm
Weight/Unit 0.00136kg
Width (W) 10.0mm
ELV compliant Dir. Art. 4 (2) YES
Flammability UL 94 V2
Hazardous Goods No
Operating Temperature -40 °C to +85 °C
Specifications
Country of Origin DE
Customs Number 39269097
GTIN-13 / EAN 4031026120027
Packaging 1 - Height (m) 0.2m
Packaging 1 - Length (m) 0.395m
Packaging 1 - Qty 500
Packaging 1 - Type Bag
Packaging 1 - Volume (m³) 0.03555
Packaging 1 - Weight (kg) 0.709135kg
Packaging 1 - Width (m) 0.45m
Packaging 3 - Height (m) 0.368m
Packaging 3 - Length (m) 0.584m
Packaging 3 - Qty 4000
Packaging 3 - Type Box
Packaging 3 - Volume (m³) 0.083
Packaging 3 - Weight (kg) 6.49308kg
Packaging 3 - Width (m) 0.386m
Packaging 4 - Height (m) 1.248m
Packaging 4 - Length (m) 1.2m
Packaging 4 - Qty 48000
Packaging 4 - Type pallet
Packaging 4 - Volume (m³) 1.198
Packaging 4 - Weight (kg) 98.904kg
Packaging 4 - Width (m) 0.8m
ETIM 7.0 Key EC000046
ETIM 8.0 Key EC000046
ETIM 9.0 Key EC000046
UNSPSC Key 39121717
