18/01/2022

HelaGuard Accessories : PACC18

Clip for Corrugated Conduits black ø18mmArticle number: 166-25708

Features

  • Easy and quick assembly with non-metallic conduits
  • Lid is integrated
  • Hole for fastening with screw
  • Inner rib prevents conduit from slipping
  • Can be used in C-shaped DIN rails

Certifications & Approvals

Colour Black (BK)
Fixation Method screw-hole
Pack Cont. 10pcs.
Package Content in Bag
PART DESCRIPTION PACC18-PA66-BK
Product Family PACC Clip for Corrugated Conduits
Product Group HelaGuard Accessories
Short Description Clip for Corrugated Conduits black ø18mm
for Hole ∅ (FH) M6
Length (L) 32mm
Nominal ∅ 18mm
Nominal ∅ (imperial) 3.94"
ELV compliant Dir. Art. 4 (2) YES
Flammability UL 94 V2
Halogenfree Yes
Hazardous good No
Material Polyamide 6.6 (PA66)
Min. Extraction Force (N) 600N
Minimum Pull trough Strength (N) 100N
Operating Temperature - °C -50 °C to +135 °C
Specifications
Country of Origin GB
Customs Number 39269097
GTIN-13 / EAN 4031026311555
Packaging 1 - Height (m) 0.04m
Packaging 1 - Length (m) 0.19m
Packaging 1 - Qty 10
Packaging 1 - Type Bag
Packaging 1 - Volume (m³) 0.00122
Packaging 1 - Weight (kg) 0.065001kg
Packaging 1 - Width (m) 0.16m
ETIM 7.0 Key EC000368
