Shrinkable markers "Ladder Style", thermal transfer : TLFX127DS-3x16YE
Shrinkable markers ladder style, thermal transfer, 2:1 (12.7 mm/6.4 mm) yellow 16 mmArticle number: 553-60049
Features
- Shrink ratio 2:1
- Halogen Free
- Low smoke propagation, density and toxicity
- 50 mm, 25 mm and 16 mm pre-cut marker options as standard, other lengths available on request
- Available in yellow or white
- Cable range 38.1 mm to 1.2 mm
- Delivery in convenient storage boxes
Certifications & Approvals
Application
TLFX DS is a halogen free European rail approved 2:1 heat shrink marker material supplied pre-cut and formatted into a convenient "ladder" system. Special material properties show low smoke propagation, density and toxicity. This pre-cut format not only allows printing on both sides of the marker but the user can also easily choose and pick each required marker. Special material properties show low smoke propagation, density and toxicity. The tubing has been especially prepared so that the print performance is excellent at all times using HellermannTyton's printer range.
More products in this product group
Shrinkable markers "Ladder Style", thermal transfer >| Application Tool | H6100, TT431, TT4030, TrakMark DS |
| Colour | Yellow (YE) |
| Fixation Method | Others |
| Pack Cont. | 4500pcs. |
| Package Quantity per | Pack |
| PART DESCRIPTION | TLFX127DS-3x16YE-PO-X-YE |
| Printable (Yes/No) | Yes |
| Product Family | TLFX DS – 2:1 Rail Limited Fire Hazard "Ladder Style" |
| Product Group | Shrinkable markers "Ladder Style", thermal transfer |
| Short Description | Shrinkable markers ladder style, thermal transfer, 2:1 (12.7 mm/6.4 mm) yellow 16 mm |
| Shrink Ratio | 2:1 |
| Variant | Thin-Wall |
| With inner glue (Yes/No) | No |
| With label space | No |
| Height (H) | 16.0mm |
| Length (L) | 16.0mm |
| Longitudinal Change After Shrinkage | -5 % max. |
| Longitudinal Change After Shrinkage test method | UL 224 |
| Print Method | Thermal transfer or laser beam printing |
| Recov. ∅ d | 6.4mm |
| Recov. ∅ d max. (imperial) | 0.25" |
| Supplied ∅ D | 12.7mm |
| Supplied ∅ D min. (imperial) | 0.47" |
| Wall (WT) | 0.700mm |
| Wall (WT) (imperial) | 0.028" |
| Width (W) | 16mm |
| Dielectric Strength | 20 kV/mm |
| Dielectric Strength test method | ASTM D2671 |
| Elongation at break | 200 % |
| Elongation at break test method | ASTM D2671 |
| ELV compliant Dir. Art. 4 (2) | YES |
| EN 45545-2 Results | R22 HL3, R23 HL3 |
| Flammability | UL 224 |
| Halogenfree | Yes |
| Hazardous good | No |
| Limited Fire Hazard | Yes |
| Material | Polyolefin, cross-linked (PO-X) |
| Minimum Shrink Temperature - °C | +100 °C |
| Operating Temperature - °C | -55 °C to +105 °C |
| Oxygen index | 37.2% |
| Recommended Ribbon Type | TTDTHOUT |
| Reel Variant | ladder-style variant |
| Shelf Life | 5 years |
| Specifications |
|
| Specifications | DIN EN 45545-2 (02/2016) |
| Tensile Strength | 11MPa |
| Test Method Tensile Strength | ASTM D2671 |
| EAN / GTIN-13 | 4031026454450 |
| Packaging 1 - Height (m) | 0.12m |
| Packaging 1 - Length (m) | 0.318m |
| Packaging 1 - Qty | 4500 |
| Packaging 1 - Type | Bag |
| Packaging 1 - Volume (m³) | 0.01271m³ |
| Packaging 1 - Weight (kg) | 2.9kg |
| Packaging 1 - Width (m) | 0.333m |
| Weight | 2.9kg |
| ETIM 6.0 | EC001530 |
| ETIM 7.0 Key | EC001530 |
| UNSPSC Key | 39131502 |
