Cable tie inside serrated, 150x3.5mm, ⌀1.5-35.0mm, grey, 100pcs.


Art.-No. 111-00924

| T30R-PA46-GY

 |

Copied
T-Series Cable Ties feature inside serrations to provide a positive hold on wire and cable bundles.
T-Series
T-Series cable ties – higher temperature resistance up to +150 °C for 5000 hours (PA46).

    • Cable tie for high temperature applications up to +150 °C (5000 h) and +195 °C (500 h)
    • Available in different sizes to cover various bundle diameters
    • Low smoke generation in the event of a fire
    • PA46 is a moisture sensitive material
    • Inside serrated cable tie offers strong hold around bundles
    • Easy application either manually or with an application tool
    • Operating temperature (long-term) up to +130 °C
    Add to watchlist
    Request quote
    Downloads e-Learning
    Application These inside serrated cable ties are made from Polyamide 4.6 (PA46). They can be applied in environments with temperatures up to +195 °C (for 500 hours) which makes them suitable for applications where a broader temperature range is required. Polyamide 4.6 is a well-known material in the automotive, railway or white goods area. An application tool is recommended to ensure greater process reliability while installing cable ties.
    Application Method Quick, simple fixing by hand or with HellermannTyton tensioning tools
    Colour Grey (GY)
    Identification Plate Position none
    Local order number T30R.RE913
    Material Polyamide 4.6 (PA46)
    Min.Tensile Strength 135N
    PART DESCRIPTION T30R-PA46-GY
    Package Content 100pcs.
    Package Content packed in Bag
    Product Family T-Series in PA46
    Product Group Cable Ties for temperatures up to + 195 °C (500 h) in Polyamide 4.6
    Releasable Closure (Yes/No) No
    Short Description Cable Tie 150x3.5 mm PA46 grey
    Tie Closure plastic pawl
    Type T30R
    UV-Stabilised No
    Variant Inside Serrated
    Bundle ⌀ 1.5-35.0mm
    Bundle ⌀ max. 35.0mm
    Bundle ⌀ min. 1.5mm
    Length (L) 150mm
    Thickness (T) 1.1mm
    Width (W) 3.5mm
    Flammability UL 94 V2
    Limited Fire Hazard Yes
    Operating Temperature -40 °C to +130 °C
    ROHS compliant Yes
    Specifications
    Country of Origin GB
    GTIN-13 / EAN 5022660331787
    Packaging 3 - Height (m) 0.192m
    Packaging 3 - Length (m) 0.586m
    Packaging 3 - Type Box
    Packaging 3 - Volume (m³) 0.0439m³
    Packaging 3 - Width (m) 0.39m
    ETIM 7.0 Key EC000046
    ETIM 8.0 Key EC000046
    ETIM 9.0 Key EC000046
    UNSPSC Key 39121703
