T-Series in PA46
Art.-No. 111-00526 | T50L-PA46 Details

  • Available in a wide range of materials and sizes
  • High tensile strength with very low insertion force
  • Only high quality plastic is used meeting recycling targets
  • Inside serrated cable ties for a strong hold onto bundles
  • Ergonomic bent tail offers quick and simple installation
  • Easy application either manually or with an application tool
Show more

Request your individual offer now

e-Learning
Application These cable ties are used for routing, bundling and securing of cables, pipes and hoses.
Application Method Quick, simple fixing by hand or with HellermannTyton tensioning tools
Application Tool ProCut 9 no battery, MK3PNSP2, EVOcut, MK7P, MK10-SB, MK20, EVO7, EVO7SP, EVO7i, EVO7iSP, EVO9, EVO9SP, EVO9i, EVO9iSP
Identification Plate Position none
Local order number T50L-N46-NA-C1
Material Polyamide 4.6 (PA46)
PART DESCRIPTION T50L-PA46
Pack Cont. 100pcs.
Product Family T-Series in PA46
Product Group Cable Ties for temperatures up to + 195 °C (500 h) in Polyamide 4.6
Releasable Closure (Yes/No) No
Short Description Cable Tie 390x4.6 PA46-natural
Tie Closure plastic pawl
Type T50L
Variant Inside Serrated
Bundle Diameter max (metric) 110mm
Bundle ∅ 1.5-110mm
Bundle ∅ min. 1.5mm
Cable Tie Head Length (metric) 7.2mm
Cable Tie Head Width (metric) 8.1mm
Length (L) 390.0mm
Min.Tensile Strength 225N
Strap Width max. (G) (imperial) 0.32"
Thickness (T) 1.2mm
Weight/Unit 0.0027kg
Width (W) 4.6mm
ELV compliant Dir. Art. 4 (2) YES
Flammability UL 94 V2
Hazardous Goods No
Limited Fire Hazard Yes
Operating Temperature -40 °C to +130 °C, (+150 °C, 5000 h; +195 °C, 500 h)
ROHS compliant Yes
Specifications
Specifications ANSI/UL 62275, csa-C22.2 no. 62275
UL OCD link Link
UL Recognized (US and Canada) Yes
UL-File Number E85319
Country of Origin SG
Customs Number 39269097
GTIN-13 / EAN 4031026269122
Packaging 1 - Height (m) 0.02m
Packaging 1 - Length (m) 0.43m
Packaging 1 - Qty 100
Packaging 1 - Type Bag
Packaging 1 - Volume (m³) 0.00099
Packaging 1 - Weight (kg) 0.270001kg
Packaging 1 - Width (m) 0.115m
Packaging 3 - Height (m) 0.218m
Packaging 3 - Length (m) 0.599m
Packaging 3 - Qty 4000
Packaging 3 - Type Box
Packaging 3 - Volume (m³) 0.0522
Packaging 3 - Weight (kg) 11.55004kg
Packaging 3 - Width (m) 0.4m
Packaging 4 - Height (m) 1.234m
Packaging 4 - Length (m) 1.2m
Packaging 4 - Qty 80000
Packaging 4 - Type pallet
Packaging 4 - Volume (m³) 1.185
Packaging 4 - Weight (kg) 252.0kg
Packaging 4 - Width (m) 0.8m
ETIM 7.0 Key EC000046
ETIM 8.0 Key EC000046
ETIM 9.0 Key EC000046
UNSPSC Key 39121703
