Fixing tie for hole (round), inside serrated, Ø1.5-16.0mm, natural, 100pcs.
Art.-No. 126-00416 | T18RSF-PA66HS-NA Details

  • Easy to assemble without the need for a tool
  • Cable tie head always situated in defined position
  • Arrowhead simply locks into place
  • Supporting legs provide a secure and firm fixing in areas where space is limited
  • Variations for round and oval holes are available
  • “Ladder style” types are very flexible
Show more

Request your individual offer now

Application For the bundling and fixing of cable harnesses, pipes and hoses in the automotive, aerospace, white goods industries and panel building.
Application Tool MK3PNSP2, EVOcut, MK7P, MK10-SB, MK20, EVO7SP, EVO7i, EVO7iSP
Cable Tie Polyamide 6, heat stabilised (PA6HS)
Colour Natural (NA)
Fixation Method arrowhead
Identification Plate Position none
Local order number T18RSF-PA66HS-NA (100)
Material Polyamide 6.6, heat stabilised (PA66HS)
Pack Cont. 100pcs.
Package Content packed in Bag
PART DESCRIPTION T18RSF-PA66HS-NA
Product Family for round holes
Product Group 1-Piece Fixing Ties with Arrowhead, with Wings
Releasable Closure (Yes/No) No
Tie Closure plastic pawl
Variant Inside Serrated
Bundle Diameter max (metric) 16.0mm
Bundle ∅ 1.5-16.0mm
Bundle ∅ min. 1.5mm
for Hole ∅ (FH) 4.65 - 4.85 mm
for Panel Thickness min - max 0.8 - 3 mm
Length (L) 100mm
Min.Tensile Strength 80N
Thickness (T) 1.0mm
Weight/Unit 0.00063kg
Width (W) 2.5mm
Width (W2) 18.5mm
ELV compliant Dir. Art. 4 (2) YES
Hazardous Goods No
Operating Temperature -40 °C to +105 °C, (+145 °C, 500 h)
Specifications
Country of Origin PL
Customs Number 39269097
GTIN-13 / EAN 4031026661483
Packaging 1 - Height (m) 0.1m
Packaging 1 - Length (m) 0.22m
Packaging 1 - Qty 100
Packaging 1 - Type Bag
Packaging 1 - Volume (m³) 0.00528
Packaging 1 - Weight (kg) 0.07198kg
Packaging 1 - Width (m) 0.24m
Packaging 3 - Height (m) 0.204m
Packaging 3 - Length (m) 0.591m
Packaging 3 - Qty 6000
Packaging 3 - Type Box
Packaging 3 - Volume (m³) 0.048
Packaging 3 - Weight (kg) 4.9688kg
Packaging 3 - Width (m) 0.398m
Packaging 4 - Height (m) 1.164m
Packaging 4 - Length (m) 1.2m
Packaging 4 - Qty 120000
Packaging 4 - Type pallet
Packaging 4 - Volume (m³) 1.117
Packaging 4 - Weight (kg) 120.4kg
Packaging 4 - Width (m) 0.8m
ETIM 7.0 Key EC000046
ETIM 8.0 Key EC000046
ETIM 9.0 Key EC000046
UNSPSC Key 39121703
